LNXS30866D

30 cu. ft. Smart wi-fi Enabled Door-in-Door® Refrigerator

KEY FEATURES

  • 30 cu. ft. Capacity
  • PrintProof™ Finish
  • SmartThinQ® Technology
  • Door-in-Door®
  • Slim SpacePlus® Ice System
  • ENERGY STAR® Qualified
30 cu. ft. Smart wi-fi Enabled Door-in-Door® Refrigerator

SUMMARY

    • Door Type
    • French 4-Door
    • Refrigerator Type
    • Door-in-Door®
    • Total Capacity
    • 29.9
    • Ice & Water Dispenser
    • Yes
    • SmartThinQ®
    • Yes
    • wi-fi Enabled
    • Yes
    • ADA Compliant
    • Yes
    • Quad Door
    • Yes
    • Standard Depth
    • Yes
    • SmartDiagnosis™
    • Yes

CAPACITY

    • Refrigerator
    • 16.80 cu. ft.
    • Freezer
    • 13.10 cu. ft.
    • Total
    • 29.9 cu. ft.

FEATURES

    • Door-in-Door® w/ ColdSaver™ Panel
    • Yes
    • ENERGY STAR® Qualified
    • Yes (778 kWh/Year)
    • Ice & Water Dispenser
    • Yes
    • Dispenser Type
    • Integrated Tall Ice & Water Dispenser®
    • Daily Ice Production
    • 4.5 lbs / 4.9 (IcePlus)
    • Ice Storage Capacity
    • 3.0 lbs
    • Water Filtration System
    • LT800P
    • Smart Cooling System
    • Yes
    • Multi Air Flow Cooling
    • Yes
    • Temperature Sensors
    • 6
    • Linear Compressor
    • Yes
    • Fresh Air Filter
    • Yes
    • Display Type
    • Smooth Touch Control (White LED)

CONVENIENCE

    • Temperature Controls
    • Electronic/Digital
    • Door Alarm
    • Yes
    • Child Lock
    • Yes
    • LoDecibel™ Quiet Operation
    • Yes
    • SmartDiagnosis™
    • Yes
    • Auto Closing Door Hinge
    • Yes

REFRIGERATOR

    • No. of Shelves
    • 4 Split (3 Fixed/1 Folding)
    • Folding Shelf
    • Yes
    • Cantilevered Shelves
    • Yes
    • Shelf Construction
    • Spill Protector™ Tempered Glass
    • Crisper Bins
    • 2 Crispers
    • EasyReach™ Bins
    • Yes
    • Refrigerator Light
    • Premium LED (Ceiling and Side)

REFRIGERATOR DOOR

    • No. of Shelves/Bin
    • 8 Total
    • Door Bin Construction
    • 1 Piece (Clear)

FREEZER

    • Door Type
    • Side Swing
    • Handle
    • Pocket Handle
    • Freezer Light
    • Premium LED

MATERIALS AND FINISHES

    • Contour Door
    • Yes
    • Hidden Hinges
    • Yes
    • Surface
    • Smooth
    • Back
    • Flush & Metal Cover Over Mechanical Parts
    • Available Colors
    • Black Stainless Steel (D)
    • Handles
    • Pocket Handles

DIMENSIONS / CLEARANCES / WEIGHTS

    • Depth with Handles
    • 36 3/8"
    • Depth without Handles
    • 36 3/8"
    • Depth without Door
    • 31 1/8"
    • Depth (Total with Door Open)
    • 49 3/4"
    • Height to Top of Case
    • 70"
    • Height to Top of Door Hinge
    • 70 1/2"
    • Width
    • 35 7/8"
    • Width (Door Open 90˚ with Handle)
    • 40 1/8"
    • Width (Door Open 90˚ without Handle)
    • 40 1/8"
    • Installation Clearance
    • Sides 1/8", Top 1", Back 2"
    • Weight (Unit/Carton)
    • 377 lbs / 408 lbs.
    • Carton Dimensions (WxHxD)
    • 38" x 73" x 39"

WARRANTY

    • Limited Warranty
    • 1 Year Parts and Labor, 5 Years on the Sealed System (Parts & Labor), 5 Years on the Compressor (Parts & Labor), 6-10 Years on Linear Compressor (Parts Only)
    • UPC
    • 048231787598

What people are saying

Rated 3 out of 5 by from Poor compressor I just bought the LG refrigerator for two years and the compressor is broken already, it is so unreliable. The overall features are good, if the LG company make the compressor more reliable, it is a great buy
Date published: 2021-02-22
Rated 1 out of 5 by from Les than 3 years old and breakdown on 4th repair! We bought this beautiful refrigerator less than 3 years ago for our AirBnB home. It has been used less than 100 days per year. It quit cooling and LG has been out 4 times to fix it and it is still lot working! We have lost over $5,000 in revenue and counting. We purchased a kitchen suite of appliances for this home. I have never had such an ineffective dishwasher either. I would NEVER buy an LG kitchen appliance again.
Date published: 2021-01-02
Rated 3 out of 5 by from Can’t believe compressor went out in 2 years Bought this 2 years ago and the compressor went out. Took LG 8 weeks to get it fixed
Date published: 2020-12-12
  • y_2021, m_4, d_16, h_17
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.14
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_36
  • loc_en_US, sid_MD05810689, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 10ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

Does this model have bluetooth capabilities? It's not important but it shows it on the diagram in the hard copy manual.

Asked by: Krogers0370
The ENERGY STAR® Qualified LG 30 cu. ft. Smart wi-fi Enabled Door-in-Door® Refrigerator, Model # LNXS30866D is a Wi-Fi enabled refrigerator, but neither the specifications nor the specification sheet shows it as supporting Bluetooth...^IFV
Answered by: Ivanf
Date published: 2019-07-15

Will model LNXS30866D  hold a standard gallon of milk in the door?

Asked by: Jac30
Hello, a gallon of milk will fit in the lowest basket of the right refrigerator door of the LNXS30866D. ^AC
Answered by: Amber C
Date published: 2018-04-16

Does this come in regular stainless steel? I love the refrigerator but I’m reluctant to buy it with all my other appliances in stainless it will be weird to have it in the black stainless. I’m going to be

Asked by: Mic Petrucelli
Hello, this unit is only available in the Black Stainless Steel. ^AC
Answered by: Amber C
Date published: 2018-02-14

If the refrigerator is going to be placed in a corner and have a wall on its right side, what is the minimum space that should be left between fridge and side wall so that the doors and drawers can be fully opened?

Asked by: andrea20
Allow at least 24 inches in front of the refrigerator to open the doors, and at least 2 inches between the back of the refrigerator and the wall for proper installation. ^CP
Answered by: ChrisPSM
Date published: 2017-12-13

I'm looking at buying a fridge soon . This new one has caught my attention. Do we know how soon till it will be out in Pennsylvania ? I really like it .

Asked by: Pamela Ann
I found it online at Costco and they also had a display in the store. The only store that displayed it. Home Depot and Lowes carry similiar but online only.
Answered by: Casey2018
Date published: 2017-12-12

Is the door-in-door area large enough to hold a standard gallon sized carton of milk?

Asked by: LuckyGoldstar123456789abc
The inner Door-in-Door compartment in the ENERGY STAR® Qualified LG Black Stainless Steel Series 30 cu. ft. 4-Door Refrigerator with Door-in-Door® will accommodate a gallon sized milk carton...^IFV
Answered by: LGJoel
Date published: 2018-04-05

What's the difference between LNXS30866D and LPXS30866D?

Asked by: SR56
The ENERGY STAR® Qualified LG Black Stainless Steel Series 30 cu. ft. 4-Door Refrigerator with Door-in-Door®, Model # LNXS30866D is a current model and the LPXS30866D is a discontinued model. The LNXS30866D has 6 Temperature Sensors, the LPXS30866D had 7. The shelving in the refrigerator compartment is different. The LPXS30866D had 4 Split (2 Sliding/1 Fixed/1 Folding) and the LNXS30866D has 4 Split (3 Fixed/1 Folding) and the LPXS30866D had a Dairy Corner Bin...^IFV
Answered by: LGJoel
Date published: 2017-10-10

Does this refrigerator LNXS30866D have measured fill water? If not why not? I'm waiting to buy this refrigerator as soon as it has measured fill water dispenser. Your instant view refrigerator has measured fill water but too expensive for me.

Asked by: Vinnny
The Measured Fill feature is a step up feature found on select LG Signature InstaView™ Door-in-Door® Refrigerators. The ENERGY STAR® Qualified LG Black Stainless Steel Series 30 cu. ft. 4-Door Refrigerator with Door-in-Door®, Model # LNXS30866D does not have this feature, it is not designed with it...^IFV
Answered by: LGJoel
Date published: 2017-05-25
