LPXS30866D

30 cu. ft. Door-in-Door® Refrigerator

KEY FEATURES

  • 30 cu. ft. Capacity
  • PrintProof™ Finish
  • Door-in-Door®
  • Slim SpacePlus® Ice System
  • ENERGY STAR® Qualified
30 cu. ft. Door-in-Door® Refrigerator

SUMMARY

    • Door Type
    • French 4-Door
    • Refrigerator Type
    • Door-in-Door®
    • Ice & Water Dispenser
    • Yes

CAPACITY

    • Refrigerator
    • 16.8 cu. ft.
    • Freezer
    • 13 cu. ft.
    • Total
    • 29.8 cu. ft.

FEATURES

    • Door-in-Door®
    • Yes
    • ENERGY STAR® Qualified
    • Yes (766 kWh/Year)
    • Dispenser Type
    • Integrated Dispenser
    • Ice System
    • Slim SpacePlus®
    • Daily Ice Production
    • 4.5 lbs / 4.8 (IcePlus)
    • Ice Storage Capacity
    • 3.0 lbs
    • Cubed Ice & Crushed Ice
    • Yes
    • Water Filtration System
    • Filter LT800P
    • Dispenser Light
    • Yes
    • Smart Cooling® Plus System
    • Yes
    • Multi-Air Flow Cooling
    • Yes
    • Temperature Sensors
    • 7
    • Linear Compressor
    • Yes
    • Fresh Air Filter
    • Yes, Air Filter LT120F
    • Display Type
    • Smooth Touch Control (White LED)
    • Temperature Controls
    • Electronic/Digital
    • Door Alarm
    • Yes
    • Child Lock
    • Yes
    • SmartDiagnosis™
    • Yes
    • Auto Closing Door Hinge
    • Yes

REFRIGERATOR

    • No. of Shelves
    • 4 Split (3 Fixed / 1 Folding)
    • Folding Shelf
    • 1
    • Cantilevered Shelves
    • Yes
    • Shelf Construction
    • Spill Protector™ Tempered Glass
    • Refrigerator Light
    • Ceiling and Side LED
    • EasyReach™ Bins
    • Yes

REFRIGERATOR DOOR

    • No. of Shelves/Bin
    • 10 Total (Including Door-in-Door®)
    • No. of Door Bins
    • 9 Total
    • Dairy Corner/Bin
    • Yes
    • Door Bin Construction
    • Clear

FREEZER

    • Door Type
    • Swing Doors
    • Drawers/Shelves
    • 6 Drawers
    • Handle
    • Pocket
    • Drawer Divider
    • Yes
    • Freezer Light
    • Premium LED
    • No. of Door Bins
    • 6

FREEZER DOOR

    • No. of Shelves/Bins
    • 6

MATERIALS AND FINISHES

    • Contour Door
    • Yes
    • Hidden Hinges
    • Yes
    • Surface
    • Black Stainless Steel
    • Back
    • Flush & Metal Cover Over Mechanical Parts
    • Available Colors
    • Black Stainless Steel (D)

SPECIFICATIONS

    • Depth with Handles
    • 36 3/8"
    • Depth without Handles
    • 36 3/8"
    • Depth without Door
    • 31.375"
    • Depth (Total with Door Open)
    • 49 3/4"
    • Height to Top of Case
    • 68.875"
    • Height to Top of Hinge
    • 70.25"
    • Height to Top of Door Hinge
    • 70 1/2"
    • Height to Top of Cover
    • 70"
    • Width
    • 35.875"
    • Width (Door Open 90° with Handle)
    • 40 1/8"
    • Width (Door Open 90° without Handle)
    • 40 1/8"
    • Installation Clearance
    • Sides 1/8", Top 1", Back 1"
    • Weight (Unit/Carton)
    • 344 lbs / 375 lbs.
    • Carton Dimensions (WxHxD)
    • 38" x 73" x 39"

WARRANTY

    • Limited Warranty
    • 1 Year Parts and Labor, 5 Years on the Sealed System (Parts & Labor), 5 Years on the Compressor (Parts & Labor), 6-10 Years on Linear Compressor (Parts Only)
    • UPC
    • 048231786751

What people are saying

Rated 5 out of 5 by from Great service 4 years after purchasing my LG refrigerator had a problem with the compressor. They came out and serviced it in one day. Works great and happy with the service.
Date published: 2021-10-11
Rated 3 out of 5 by from Compressor died The compressor died.I have had two repair visits, and still not fixed. Third vist comin as soon as parts come.
Date published: 2021-09-25
Rated 4 out of 5 by from OKay I bought this item 4 years ago. Remodel may Kitchen for my wife.
Date published: 2021-08-23
  • y_2021, m_10, d_26, h_18
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.19
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_47
  • loc_en_US, sid_MD05167320, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 12ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

What is a part number of door-in-door compartment where milk goes? It cracked and I need to replace it. And where can I get it as I see fridge was discontinued Thank you

Asked by: Ira78
Let's see if we can get that taken care of for you. Send us a message on Twitter at @LGUSSupport or on Facebook https://www.facebook.com/LGUSA/ so we can get more info and see what we can do. ^CP
Answered by: ChrisPSM
Date published: 2019-06-28

How do we fix freezer (F5 and fridge E). We had 2 service men out. They both say it’s a mother board and sensor. At point after hundreds of dollars out.We want to take care of ourselves. which one to purchase. Gaskets are clean.

Asked by: Knight1
We are sorry to see you are experiencing an issue with your refrigerator. We would be happy to look into the available repair options with you. Drop us a line on Twitter at @LGUSSupport or on Facebook https://www.facebook.com/LGUSA/ or you can give us a call at 800-243-0000 so we can get more info and see what we can do. ^CP
Answered by: ChrisPSM
Date published: 2019-02-21

What is the part number for the lower bin on the inside of the left door, in front of the filter. It broke and I need to order a new one.

Asked by: Brwnidgirl
Hello, the part number is AAP74271303 and can be purchased in the link provided. ^AC http://lge.andrewselectronics.com/search/electronic-parts/parts/9/AAP74271303
Answered by: Amber C
Date published: 2018-07-16

We have room in our kitchen for the 30866D, but the widest door into the kitchen is less than 31" wide.  Can the doors be removed to deliver the refrigerator ?

Asked by: Thornton DG
Removing the doors or handles from a refrigerator and moving it on its side through a narrow opening is the recommended procedure. You need to alert the retailer from where you purchase the refrigerator that the doors will need to remove the doors to get it through your doors so the delivery team brings the right tools with them. However, the ENERGY STAR® Qualified LG 30 cu. ft. Door-in-Door® Refrigerator, Model # LPXS30866D has a depth of 31.375" (i.e 31 3/8") with the door removed so if your opening is less than 31", it will not fit through...^IFV
Answered by: LGJoel
Date published: 2018-06-04

Love my LPXS30866, have had it since 6-16. My ice maker and freezer have suddenly stopped working. Help!

Asked by: Margo R
Hello, sounds like you need a technician. Please give us a call at 1-800-243-0000 when you are with the unit. ^AC
Answered by: Amber C
Date published: 2018-03-08

HI, MADE IN WHERE PLEASE? THANKS

Asked by: GRONE2017
We have manufacturing plants located worldwide and would not be able to answer that until the unit is bought. ^AC
Answered by: Amber C
Date published: 2018-06-12

How do yo turn the temperature up on the refrigerator and freeEr

Asked by: Hilldw52
We appreciate your interest in this refrigerator. The temperature settings are on loop control. Continue pressing the REFRIGERATOR button until it reaches its lowest setting. Press it again, and the setting should jump to its HIGHEST setting. The same would work for the FREEZER. ^CP
Answered by: ChrisPSM
Date published: 2018-02-17

Does this fridge come in stainless. Or is it only black stainless.

Asked by: Lee Coleman
HI Lee. The ENERGY STAR® Qualified LG Black Stainless Steel Series 30 cu. ft. 4-Door Refrigerator with Door-in-Door®, Model # LPXS30866D is only available in Black Stainless Steel...^IFV
Answered by: LGJoel
Date published: 2018-01-10
