Discontinued
22LB4510
22'' Class (21.5'' Diagonal) 1080p LED TV
  • 1920 x 1080 Resolution
  • MCI 120
  • 2Ch Speaker System
22" Class (21.5" Diagonal) 1080p LED TV

SUMMARY

  • Screen Size
    22"

PANEL SPECIFICATIONS

  • Screen Size Class (diagonal)
    22" Class (21.5" diagonal)
    Resolution
    1920 x 1080
  • MCI
    120

DIMENSIONS / WEIGHT

  • TV without Stand (WxHxD)
    20" x 12.4" x 2.2"
    TV with Stand (WxHxD)
    20" x 14.1" x 5.6"
  • TV without Stand weight
    6.17 lbs
    TV with Stand weight
    6.61 lbs
  • TV Shipping Dimensions (WxHxD)
    26" x 15" x 5"
    Shipping Weight
    9.26 lbs

VIDEO

  • Picture Mode
    8 Modes (Vivid, Standard, Cinema, Sport, Game, Photo, Eco, Expert1, Expert2)
    Aspect Ratio
    8 Modes (16:9, Just Scan, Original, 4:3, Cinema Zoom, Zoom, Full Wide, 14.9 Zoom)
  • Just Scan (1:1 Pixel Matching)
    HDMI: 1080i, Component: 1080p, RF 720p
    AV Mode II
    3 Modes (Cinema/Game/Off)

AUDIO

  • Speaker System
    1 Way, 2 Speakers
    Audio Output Power (Watts - THD 10%)
    5W + 5W
  • Virtual Surround
    Yes
    Clear Voice II
    Yes

USB

  • Video
    MPEG1, MPEG2
    Audio
    MP3
  • Photo
    JPEG, JPG

AV INPUTS/OUTPUTS

  • RF In (Antenna/Cable)
    1 (Rear)
    AV In
    1 (Rear)
  • Component Video In(Y, Pb, Pr + Audio)
    1 (Rear)
    HDMI™/ HDCP In
    1 (rear)
  • RGB In (D-Sub 15 Pin) - PC
    1 (Rear)
    PC Audio Input
    1 (Rear)
  • USB 2.0
    1 (Side)

CABINET / ACCESSORIES

  • VESA® Size (mm)
    75 x 75
    Remote Control
    Yes
  • Batteries
    AA x 2

POWER

  • Power Supply (Voltage, Hz)
    100V ~ 240V, 50/60 Hz
    Standby Mode
    0.4W

WARRANTY / UPC

  • Limited Warranty
    1 Year Parts & Labor
    UPC
    719192194052
What people are saying
Rated 5 out of 5 by from Christmas has finally arrived This was a 2014 Christmas gift, but my living conditions did not permit installation until last week. It's a big 22 inches of beautiful color and sound. Now I find myself wishing I could stay home more and watch...not really. I'm fortunate to have an active volunteer life, do not look forward to slowing down, but know I have a wonderful TV to enjoy when that time comes.
Date published: 2017-05-01
Rated 3 out of 5 by from Great midrange TV I use this TV primarily for playing video games, and after changing the default configuration around a little bit, I was able to get great image! However, the sound is mediocre, and it doesn't do very well in bright rooms. For the price, however, I'd say it's worth the inconvenience if you're looking for something small.
Date published: 2015-02-07
Rated 4 out of 5 by from Very Pleased except for one item. Ear Phone jack missing. While this may not be an important item for many situations, if two TV's are within earshot of each other (kitchen and living room) the dueling volume battles can become legendary. This is a kitchen TV mounted on an articulating arm and it works great with a satellite link.
Date published: 2015-01-03
  • y_2019, m_10, d_18, h_22
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.13
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_7
  • loc_en_US, sid_MD05094187, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 264ms
  • REVIEWS, PRODUCT
ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

Do you sell the power cord and Controller for this TV? We lost ours

Asked by: Chtaylor
Our offices, in the United States, do not have product information for Canada. In order to obtain such information, it is recommended to check our subsidiary’s website, at http://www.lg.com/ca_en/index.jsp. You may also contact our Canada offices at 1-888-542-2623..
Answered by: NeilE
Date published: 2016-11-14

I NEED A POWER SUPPLY FOR MY TV LG 22 MODEL 22LB4510, WHERE I CAN GET A POWER SUPPLY I LOST MINE.

Asked by: ROGER LACHAPELLE
Our offices, in the United States, do not have product information for Canada. In order to obtain such information, it is recommended to check our subsidiary’s website, at http://www.lg.com/ca_en/index.jsp. You may also contact our Canada offices at 1-888-542-2623.
Answered by: NeilE
Date published: 2016-10-27

Should I have audio when using HDMI cable only?!

Asked by: Tasha_sh
Regardless of whether the HDMI port is on the Energy Star® Qualified LG 22" Class (21.5" Diagonal) 1080p LED TV, Model # 22LB4510 or another TV regardless of brand or other product, it has an industry standard and all HDMI ports carry both the video and audio signals. When using an HDMI cable, if your source input is switched to the appropriate input on your TV to which you have the HDMI cable connected to from the device that you want to hear the audio from, you should have audio...^IFV
Answered by: LGJoel
Date published: 2016-05-06

Is it possible to purchase a stand for this tv? Did not come with one originally when it was purchased by my mother in law for our daughters room.

Asked by: Doobs413
Accessories can be obtained through our parts distributor, MCM Electronics. Their contact number, for placing orders, is 800-824-9491. You can also use their website, at http://www.mcmelectronics.com/content/en-US/forms/lg_parts. The part number for this Base Assembly is AAN74510824. If needed, the part number for the Hinge Cover is MCK67924514.
Answered by: NeilE
Date published: 2015-10-02

Does it have Audio Out jacks?

Can I connect headphones, external speakers, audio bluetooth adapter, etc, for the purpose of alternate audio output?
Asked by: Joseph101
I apologize, but no; this television has not been designed with a headphone jack, nor with any other audio output connection or configuration.
Answered by: NeilE
Date published: 2015-03-25

why most channels not full screen

Our other tv a jvc all channels on cable full screen
Asked by: craigb1
Full screen is dependent on the aspect ratio settings. This set has 8 Modes (16:9, Just Scan, Original, 4:3, Cinema Zoom, Zoom, Full Wide, 14.9 Zoom).
Answered by: BubbaJim
Date published: 2015-04-04

DOES THIS TV SCREEN TILT UP OR DOWN?

Model: 22LB4510 LG - 22" Class (21-1/2" Diag.) - LED - 1080p - 120Hz - HDTV
Asked by: Anonymous
No. The standard stand that comes with this set does not have any tilt or swivel capability.
Answered by: BubbaJim
Date published: 2015-01-06

3 questions: screen reflection, RF resolution, PC input

Does this model have a matte (non-glare) screen, or do I need to be careful about room or window reflections? Specs say 720p for RF input. Does this mean I can't display full HD from over-the-air HD broadcast stations? Is the video input from a PC a standard VGA connection? TV model 22LB4510 Thanks!
Asked by: Semibs
1. The screen is not a glossy screen, but you may pick up some glare or reflection from room windows. 2. The 22LB4510 model I have is advertised as full HD 1080P resoulution. The native display resolution is 1920 x 1080 unless you set it differently during set-up. 3. PC input is via an RGB connector.
Answered by: BubbaJim
Date published: 2015-01-06
