SUMMARY
-
- Design Style
- Front Loader
- TwinWash™ Compatible
- Yes
-
- Stackable
- Yes
- Energy Star Qualified
- Yes
-
- Energy Star® MOST EFFICIENT
- Yes
- Capacity (cu.ft.)
- 4.3 cu. ft.
-
- Dimensions (WxHxD)
- 27" x 38 11/16" x 29 3/4" (51" D with door open)
- Available Colors
- White (W)
CAPACITY
-
- Capacity
- 4.3 cu. ft.
APPEARANCE
-
- Intelligent Electronic Controls with Dual LED Display
- Yes
- Dial-A-Cycle™
- Yes
ENERGY
-
- 2016 ENERGY STAR® Most Efficient
- Yes
WASH PROGRAMS
-
- No. of Programs
- 7
- Wash Programs
- Cotton/Normal, Bulky/Large, Perm. Press, Delicates, Speed Wash, Tub Clean, Download/Small Load
-
- No. of Options
- 9
- Options
- Prewash, Rinse+Spin, Delay Wash, Water Plus, Extra Rinse, Child Lock, ColdWash™, FreshCare™, Custom Program
-
- No. of Wash/Rinse Temps
- Extra Hot, Hot, Warm, Cold, Tap Cold (All Cold Rinses)
- Spin Speeds
- Extra High (1,300 max.), High, Medium, Low, No Spin
-
- No. of Water Levels
- Automatically adjusts to the size of load
- No. of Soil Levels
- 5
FABRIC CARE FEATURES
-
- ColdWash™ Option
- Yes
- SenseClean™ System
- Yes
CONVENIENCE FEATURES
-
- 4 Tray Dispenser
- Prewash, Main Wash (with liquid detergent cup), Bleach, Fabric Softener
- TrueBalance™ Anti-Vibration System
- Yes
-
- SmartDiagnosis™
- Yes
- LoadSense
- Yes
-
- Status Indicator(s)
- Yes
- End of Cycle Signal
- Yes
-
- Child Lock
- Yes
- Auto Suds Removal
- Yes
-
- Forced Drain System
- Yes
- LoDecibel™ Quiet Operation
- Yes
-
- Leveling Legs
- 4 Adjustable Legs
- Easy Loading 10° TilTub™
- Yes
MOTOR AND AGITATOR
-
- Motor Type
- Direct Drive Motor
- Motor Speed
- Variable
-
- Max RPM
- 1,300
- Axis
- Horizontal
MATERIALS AND FINISHES
-
- NeveRust™ Stainless Steel Drum
- Yes
- Cabinet
- PCM
-
- Control Panel
- Plastic
- Top Plate
- Painted
-
- Transparent Glass Door
- Yes
- Door Rim
- Silver Spray Rimmed Glass Door
-
- Available Colors
- White (W)
ACCESSORIES
-
- Hose Included
- Yes
POWER SOURCE
-
- Ratings
- UL Listed
- Electrical Requirements
- 120V, 10 Amps
-
- Type
- Electric
OPTIONS
-
- Pedestal
- WDP4W
- Pedestal (WxHxD)
- 27" x 13 3/5" x 28 2/5"
-
- Stacking Kit
- KSTK1
DIMENSIONS
-
- Product (WxHxD)
- 27" x 38 11/16" x 29 3/4" (51" D with door open)
- Carton (WxHxD)
- 29 1/2" x 43 5/16" x 31 5/16"
-
- Weight (Product/Carton)
- 196.2 lbs/212.7 lbs
WARRANTY
-
- Limited Warranty
- 1 Year Parts and Labor 10 Years Motor, Lifetime on Drum
- UPC
- 048231014731
What people are saying
Rated 4 out of
5
by
EGOwner from
Wonderfully efficient washer, the first two years
Our old top load agitator washing machine could no longer be repaired, so we moved up to a front load. At least it still washes well, is very efficient with water and electricity, and has many good features which we use. No WiFi, which is fine. We don't need WiFi on a washer, or a screen on a refrigerator. Just give us an appliance which works well for a couple decades, like our old washer. We were very happy with our LG for the first two years, but since, loads have become unbalanced often and the washer walks around the laundry room.
We are on a concrete slab so the floor doesn't shift, have not changed the leveling feet, and not overloaded our washer, yet we worry that the internal drum supports may be loosening or the bearings may be going.
Any support from LG? Not really. We are out of warranty, so tough luck. Call a repair person. We will continue sliding this heavy washer back into place every time it walks (and keep the door to the laundry room open, so the walking washer doesn't block the door).
Date published: 2022-05-16
Rated 4 out of
5
by
EG Owners from
Bst washer, but large loads cause imbalanced spin
For the first few years, we have been very happy with our LG washing machine. It is much more efficient than our old top loaders, spun water out much better to shorten drying times, and treated delicates with care. Unfortunately, large loads now get out of balance often, requiring us to stop the cycle to redistribute the clothes. This never occurred the first few years. Now, we have even had it “walk” almost 2 feet when unbalanced. We are on a concrete slab, so our floor has not changed and we checked the feet to be certain that no corners were causing the imbalance. Unfortunately LG customer support had no suggestions, other than redistributing clothes and checking the feet. We are now out of warranty, so any repair call will be expensive. Why would LG not tell us how to safely open the top to check the tub mountings to determine if they had loosened? We just hope it doesn’t blow the door open on a high speed spin.
Date published: 2022-04-16
Rated 5 out of
5
by
Magee50 from
Doing the job
So far so good. Attractive and easy to use. Electric cable too short and so I had to purchase and attach a longer wire.
Date published: 2022-04-05
We're here to support you with our product.
View WM3170CW Product Support
-
Warranty Information View manufacturer warranty information Learn more
-
Register Your Product Get the most out of your ownership Learn more
-
Manuals and Downloads Download owner's manuals and documentation Learn more
-
Help Library Help yourself to helpful product information Learn more
-
Video Tutorials Learn how to install & operate your LG product Learn more
-
Request a Repair Submit an online service request Learn more
-
Other Support Options More help with your LG product Learn more
Choose a support option below:
-
LG Chatbot 24x7 Support with Chatbot!
-
Telephone Call an LG Support Representative
(800) 243-0000 Consumer 6am-midnight CST -
Twitter Tweet @LGUSSupport
for Support. Mon-Sat 8:00am-7:00pm CST -
Email No time to chat? Send LG Support your inquiry.
ASK & ANSWER
Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.
Are these stackable?
Yes, the WM3170CW is a stackable unit.
Date published: 2020-10-05
what dryer would match this
The matching dryer for the ENERGY STAR® Qualified LG 4.3 cu. ft. Ultra-Large Capacity with NFC Tag On Technology, Model # WM3170CW was the ENERGY STAR® Qualified LG 7.4 cu. ft. Ultra Large Capacity Electric Dryer w/ NFC Tag On Technology, Model # DLE3170W and the ENERGY STAR® Qualified LG 7.4 cu. ft. Ultra Large Capacity Gas Dryer w/ NFC Tag On Technology, Model # DLG3171W. Both those dryers are discontinued dryers, but any of our current 27" 7.4 cu. ft. Smart wi-fi Enabled Electric Dryer with Sensor Dry Technology or 7.4 cu. ft. Smart wi-fi Enabled Gas Dryer with Sensor Dry Technology or 7.3 cu. ft. Electric/Gas Dryers with Sensor Dry Technology will match the washer...^IFV
Date published: 2019-11-11
What pedestal are compatible with this washer WM3170CW
The WM3170CW is compatible with the WDP4W pedestal. ^CP
Date published: 2019-11-17
Is it possible to get this model with the door hinge on the right so that it opens to the left?
We are sorry but the washing machines cannot have their doors revised, but the dryers can. ^AC
Date published: 2022-04-28
Who’s the LG washers and dryers manufacturer
LG manufactures its own washers and dryers...^IFV
Date published: 2017-11-22
Can the washer be used with your mobile phone
YES
Date published: 2017-05-06
What is de2 code
We regret the trouble you have experienced with this washing machine. The dE2 code denotes a door error. It is recommended to check the door seal and door frame for obstructions. Be certain that the door is completely closed, locked and free from clothing or other items. Once this has been checked, if the error still occurs, then the washer may require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Date published: 2017-03-17
i used the Smart diagnosis feature on my smart phone and said I need to run bucket sterilization cycle. I only see a tub clean cycle, is that the same thing?
We appreciate your interest in this washing machine. Yes, these 2 labels should be the same feature.
Date published: 2017-02-22
