UH5F-H Series

55UH5F-H

Key Features

Brightness(Typ.) : 500 cd/m²
Surface Treatment (Haze) : 28%
Bezel : 9.9 mm (T/R/L), 14.4 mm (B)
Depth : 39.9 mm
Interface : HDMI(3)/DP/DVI-D/USB 2.0/ RS232C/ RJ45/ Audio/ IR
30º Tilting Installation

All Spec

ACCESSORY

Basic: Remote Controller(include battery 2ea), Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender

Optional: Stand(ST-653T), Wall bracket(LSW350B), VESA Adapter(AM-B330S), OPS Kit(KT-OPSF)

CERTIFICATION

Safety: CB / NRTL

EMC: FCC Class "A" / CE / KC

ErP / Energy Star: Yes / Energy Star 8.0

CONNECTIVITY

Input - Digital - HDMI: Yes(3)HDMI1/HDMI2 : HDCP 2.2/1.4HDMI3 : HDCP 1.4

Input - Digital - DP: Yes(1), HDCP2.2/1.3

Input - Digital - DVI-D: Yes(1), HDCP1.4

Input - Audio In: Yes(1)

Input - External Control - RS232C IN: Yes(1), 4pin Phone-jack

Input - External Control - RJ45(LAN): Yes(1)

Input - External Control - IR IN: Yes(1)

Input - USB: USB2.0 Type A(1)

Output - DP Out: Yes(1), Input : HDMI1/2/3/DVI/DP/OPS

Output - Audio Out: Yes(1)

Output - External Control - RS232C OUT: Yes(1), 4pin Phone-jack

ENVIRONMENT CONDITIONS

Operation Temperature: 0 °C to 40 °C

Operation Humidity: 10 % to 80 %

MECHANICAL SPECIFICATION

Bezel Color: Black

Bezel Width: T/R/L: 9.9mm, B: 14.4mm

Weight(Head): 19.0Kg

Weight(Head+Stand): 19.6Kg

Packed Weight: 24.2 kg

Monitor Dimension(W x H x D): 1234.4 x 720.9 x 39.9mm

Monitor Dimensions with Stand(W x H x D): 1234.4 x 770.7 x 290.0mm

Carton Dimensions(W x H x D) (Box outer size): 1360.0 x 835.0 x 175.0mm

VESA™ Standard Mount Interface: 300 x 300

PANEL

Screen Size: 55"

Panel Technology: IPS

Back Light Type: Edge

Aspect Ratio: 16:9

Native Resolution: 3840 x 2160 (UHD)

Refresh Rate: 60Hz

Brightness: 500nit (Typ.)

Contrast Ratio: 1,100:1

Dynamic CR: 1,000,000:1*The luminosity ratio of Full Black / Full White color on video input condition.

Color Gamut: BT709 95%

Viewing Angle(H x V): 178 x 178

Color Depth: 10bit, 1.07Billion colors

Response Time: 8ms (G to G)

Surface Treatment(Haze): 28%

Life time: 50,000Hrs (Min.)

Operation Hours (Hours/Day): 24/7

Portrait / Landscape: Yes / Yes

POWER

Power Supply: AC 100-240V~, 50/60Hz

Power Type: Built-In Power

POWER CONSUMPTION

Typ.: 105W

Max.: 145W

BTU (British Thermal Unit): 0 BTU/Hr(Typ.), 0 BTU/Hr(Max)

Smart Enegy Saving: 84W

DPM: 0.5W

Power Off: 0.5 W

SOFTWARE COMPATIBILITY

SuperSign CMS: Yes

SuperSign Control / Control+: Yes / Yes

SuperSign WB: Yes / Yes

SuperSign Media Editor: Yes / Yes

Signage 365 Care: Yes (The availability can differ by region.)

SOUND

Speaker: Yes

SPECIAL FEATURE

Tilt (Facedown): Yes (Max 30º degree, 30ºC temperature, humidity 50%)

IP Rating: IP5x

KEY FEATURE

HW - Internal Memory: 8GB

HW - Wi-Fi - Built-in: Yes

HW - Sensor - Temperature Sensor: Yes

HW - Sensor - Auto Brightness sensor: Yes

HW - Sensor - Acceleration(Gyro) Sensor: Yes

HW - Local Key Operation: Yes

SW - webOS ver.: webOS 4.1

SW - Embedded CMS - Local Contents Scheduling: Yes

SW - Embedded CMS - Group Manager: Yes

SW - USB Plug & Play: Yes

SW - Fail over: Yes

SW - Background Image - Booting Logo Image: Yes

SW - Background Image - No Signal Image: Yes

SW - Sync Mode - RS-232C Sync: Yes

SW - Sync Mode - Local Network Sync: Yes

SW - Multi-screen - PIP: Yes

SW - Multi-screen - PBP: Yes(4)

SW - Screen Share: Yes

SW - Video Tag: Yes(4)

SW - Play via URL: Yes

SW - Rotation - Screen Rotation: Yes

SW - Rotation - External Input Rotation: Yes

SW - Gapless Playback: Yes

SW - Tile Mode Setting: Yes(Max. 15x15)

SW - Setting Data Cloning: Yes

SW - SNMP: Yes

SW - ISM Method: Yes

SW - Auto Set ID: Yes

SW - Status Mailing: Yes

SW - Control Manager: Yes

SW - 3rd Party Compatibility - Crestron Inside: Yes *Network based control

SW - Smart Energy Saving: Yes

SW - PM mode: Yes

SW - Wake on LAN: Yes

SW - Beacon: Yes

SW - HDMI-CEC: Yes *Compatibility may differ by equipment.

SW - SI Server Setting: Yes

SW - webRTC: Yes

SW - Pro:Idiom: Yes

OPS COMPATIBILITY

OPS type compatible: Yes

LANGUAGE

OSD: English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Turkish, Arabic
