Environment
RoHS
Pixel Configuration
Single SMD
Pixel Pitch (mm)
3.91
Module Resolution (WxH)
64x128
Module Dimensions(WxH,mm)
250x500
Weight per Module (kg)
1.40
No. of Modules per Cabinet (WxH)
2x2
Cabinet Resolution (WxH)
128x256
Cabinet Dimensions (W x H x D, mm)
500x1000x66.05
Cabinet Surface Area (㎡)
0.500
Weight per Cabinet (kg/unit)
12.4
Weight per Square Meter (kg/㎡)
24.9
Physical Pixel Density (pixels/㎡)
65,536
Flatness of Cabinet (mm)
±0.3
Cabinet material
Die-casting Magnesium
Service access
Front or Rear (select one only)
Controller
(MVR HEIOS)
IP rating Front
IP30
IP rating Rear
IP30
LED Lifetime (Half brightness)
100,000
Operating Humidity
10~99%RH
Operating Temperature(℃)
-30℃ to +45℃
Frame Rate (Hz)
50 / 60
Heat Dissipation (BTU/h/Cabinet, Avg.)
341
Heat Dissipation (BTU/h/Cabinet, Max.)
1,024
Heat Dissipation (BTU/h/㎡, Max.)
2,047
Power Consumption (W/Cabinet, Avg.)
100
Power Consumption (W/Cabinet, Max.)
300
Power Consumption (W/㎡, Max.)
600
Power Supply (V)
100 to 240
Refresh Rate (Hz)
3,840
Max Brightness (After Calibration, nit)
5,000
Color Temperature (K)
2,000-11,000
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
155
Brightness Uniformity
0.97
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
6,000:1
Processing Depth (bit)
16 (PQ, HLG)
Certification
CE, FCC, ETL
