Model name
LSGA026-GK
Pixel Configuration
Single SMD
Pixel Pitch (mm)
2.6
Module Resolution (WxH)
96x96
Module Dimensions(WxH,mm)
250x250
Weight per Module (kg)
0.55
No. of Modules per Cabinet (WxH)
2x4
Cabinet Resolution (WxH)
192x384
Cabinet Dimensions (W x H x D, mm)
500x1,000x90
Cabinet Surface Area (㎡)
0.5
Weight per Cabinet (kg/unit)
10
Weight per Square Meter (kg/㎡)
20
Physical Pixel Density (pixels/㎡)
147,456
Flatness of Cabinet (mm)
±0.1
Cabinet material
Magnalium
Service access
Front & Rear
Max Brightness (After Calibration, nit)
800
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
140
Brightness Uniformity
0.98
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
6,500:1
Processing Depth (bit)
14
Power Consumption (W/Cabinet, Max.)
196
Power Consumption (W/Cabinet, Avg.)
66
Power Consumption (W/㎡, Max.)
392
Heat Dissipation (BTU/h/Cabinet, Max.)
535
Heat Dissipation (BTU/h/Cabinet, Avg.)
180
Heat Dissipation (BTU/h/㎡, Max.)
1,070
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
-10℃ to +40℃
Operating Humidity
10~80%RH
IP rating Front
IP40
IP rating Rear
IP20
Certification
CE, FCC, cTUVus, CB
Environment
RoHS, REACH
Controller
CVGA
