Model name
GPEJ100-GN
Pixel Configuration
Single SMD
Pixel Pitch (mm)
10.00
Module Resolution (WxH)
40 × 30
Module Dimensions(WxH,mm)
400x300
Weight per Module (kg)
1.65
No. of Modules per Cabinet (WxH)
4X3
Cabinet Resolution (WxH)
160x90
Cabinet Dimensions (W x H x D, mm)
1,600x900x105
Cabinet Surface Area (㎡)
1.440
Weight per Cabinet (kg/unit)
55.0
Weight per Square Meter (kg/㎡)
38.2
Physical Pixel Density (pixels/㎡)
14,400
Flatness of Cabinet (mm)
±1.0
Cabinet material
Al
Service access
Front and Rear
Max Brightness (After Calibration, nit)
6,000
Color Temperature (K)
3,500~8,500
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
110
Brightness Uniformity
97%
Color Uniformity
±0.05Cx,Cy
Contrast Ratio
7,000:1
Processing Depth (bit)
16 (HDR10, HDR10 Pro)
Power Consumption (W/Cabinet, Max.)
1,000
Power Consumption (W/Cabinet, Avg.)
400
Power Consumption (W/㎡, Max.)
694
Heat Dissipation (BTU/h/Cabinet, Max.)
3,413
Heat Dissipation (BTU/h/Cabinet, Avg.)
1,365
Heat Dissipation (BTU/h/㎡, Max.)
2,368
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
7,680
Operating Temperature(℃)
-30°C to +50°C
Operating Humidity
0~90%RH
IP rating Front
IP65
IP rating Rear
IP65
LED Lifetime (Half brightness)
100,000
Certification
CE, FCC, ETL
Environment
RoHS, REACH
Controller
CVEA
