Pixel Configuration
3 in 1 SMD
Pixel Pitch (mm)
3.91
Module Resolution (WxH)
64 × 128
Module Dimensions(WxH,mm)
250 × 500
Weight per Module (kg)
1.40
No. of Modules per Cabinet (WxH)
2 × 2 / 2 × 1 (Half-sized)
Cabinet Resolution (WxH)
128 × 256 / 128 × 128 (Half-sized)
Cabinet Dimensions (W x H x D, mm)
500 × 1,000 × 66.05
500 × 500 × 66.05 (Half-sized)
Cabinet Surface Area (㎡)
0.500 / 0.250 (Half-sized)
Weight per Cabinet (kg/unit)
12.5 / 7.9 (Half-sized)
Weight per Square Meter (kg/㎡)
24.9 / 31.7 (Half-sized)
Physical Pixel Density (pixels/㎡)
65,536
Flatness of Cabinet (mm)
± 0.3 mm
Cabinet material
Die-casting Magnesium
Service access
Front or Rear (One Option Only)
Model name
GSCA039-GN
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
155
Brightness Uniformity
97%
Color Uniformity
± 0.003 Cx,Cy
Contrast Ratio
6,000
Processing Depth (bit)
14
Color Temperature
3,500 ~ 9,000
Power Consumption (W/Cabinet, Max.)
300 / 150 (Half-sized)
Power Consumption (W/Cabinet, Avg.)
100 / 50 (Half-sized)
Power Consumption (W/㎡, Max.)
600
Heat Dissipation (BTU/h/Cabinet, Max.)
1024 / 512 (Half-sized)
Heat Dissipation (BTU/h/Cabinet, Avg.)
341 / 171 (Half-sized)
Heat Dissipation (BTU/h/㎡, Max.)
2047
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Operating Temperature(℃)
-20℃ to +45℃
Operating Humidity
10-99%RH
IP rating Front
IP65
IP rating Rear
IP65
Environment
RoHS
Controller
LCIN006
