Model name
GSED025-GD
Pixel Configuration
Single SMD
Pixel Pitch (mm)
2.50
Module Resolution (WxH)
96x108
Module Dimensions(WxH,mm)
240x270
Weight per Module (kg)
1.05
No. of Modules per Cabinet (WxH)
2 x 2
Cabinet Resolution (WxH)
192x216
Cabinet Dimensions (W x H x D, mm)
480x540x70
Cabinet Surface Area (㎡)
0.260
Weight per Cabinet (kg/unit)
8.5
Weight per Square Meter (kg/㎡)
32.7
Physical Pixel Density (pixels/㎡)
160,000
Flatness of Cabinet (mm)
±1.0
Cabinet material
Aluminum
Service access
Front and Rear
Max Brightness (After Calibration, nit)
4,000
Color Temperature (K)
3,500~8,500
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
140
Brightness Uniformity
97%
Color Uniformity
±0.05Cx,Cy
Contrast Ratio
4,000:1
Processing Depth (bit)
16 (HDR10, HDR10 Pro)
Power Consumption (W/Cabinet, Max.)
180
Power Consumption (W/Cabinet, Avg.)
72
Power Consumption (W/㎡, Max.)
694
Heat Dissipation (BTU/h/Cabinet, Max.)
614
Heat Dissipation (BTU/h/Cabinet, Avg.)
246
Heat Dissipation (BTU/h/㎡, Max.)
2,368
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
Operating Temperature(℃)
-30°C to +50°C
Operating Humidity
0~90%RH
IP rating Front
IP65
IP rating Rear
IP65
LED Lifetime (Half brightness)
100,000
Certification
CE, FCC, ETL
Environment
RoHS, REACH
Controller
CVEA
90 degree corner cut
Yes
