UH5E Series

UH5E Series

UH5E Series

86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B
LG UH5E Series, 86UH5E-B

Key Features

  • Brightness(Typ.) : 500 cd/m²
  • Bezel : 14.3 mm (Even, Off-Bezel)
  • Depth : 60.6 mm (without Handle and Logo)
  • Interface : HDMI(3)/DP/DVI-D/USB 2.0(2)/ RS232C/ RJ45/ Audio/ IR
  • Built-in Speaker(10W+10W)
More
Print

All Spec

PANEL

  • Screen Size

    86"

  • Resolution

    3,840 x 2,160 (UHD)

  • Brightness(Typ.,cd/m²)

    500

CONNECTIVITY

  • Input

    HDMI (3), DP, DVI-D, Audio, USB 2.0 (2)

  • Output

    DP, Audio (Off/Fixed/Variable)

  • External Control

    RS232C In/out (4 Pin Phone-Jack), RJ45 (LAN) In, IR In

MECHANICAL SPECIFICATION

  • Bezel Width

    14.3 mm (Even) * Off-Bezel

  • Monitor Dimension (W × H × D)

    1,926.2 x 1,097.2 x 60.6 mm (without Handle and Logo)

  • Weight (Head)

    49kg

  • Carton Dimensions (W × H × D)

    2,073 x 1,260 x 292 mm

  • Packed Weight

    61.1kg

  • VESA™ Standard Mount Interface

    600 x 400 mm

ENVIRONMENT CONDITIONS

  • Operation Temperature

    0°C to 40°C

  • Operation Humidity

    10% to 80%

POWER

  • Power Supply

    100-240V~, 50/60Hz

  • Power Type

    Built-In Power

POWER CONSUMPTION

  • Typ. / Max.

    215W/280W

  • Smart Energy Saving

    151W

CERTIFICATION

  • Safety

    CB / NRTL

  • EMC

    FCC Class "A"/CE/KC

  • ErP / Energy Star

    Yes (EU Only) / N/A

MEDIA PLAYER COMPATIBILITY

  • OPS Type Compatible

    Yes

SOFTWARE COMPATIBILITY

  • Content Management Software

    SuperSign CMS

  • Control and Monitoring Software

    SuperSign Control / Control+

ACCESSORY

  • Basic

    Remote Controller, Power Cord, QSG, DP Cable (1.8M), Regulation Book, Phone to RS232C Gender

  • Optional

    OPS Kit (KT-OPSF), Wall Mount (LSW640A/B)

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
