DLGX3701V

7.4 cu. ft. Ultra Large Capacity Smart wi-fi Enabled SteamDryer™

Graphite Steel
$1,199.99
7.4 cu. ft. Ultra Large Capacity Smart wi-fi Enabled SteamDryer™
$ 1,199.99

Warranty / Certifications

COMPLETE YOUR SYSTEM

See compatible products below:

CLICK BELOW TO SEE THE ELECTRIC DRYER MODEL

SUMMARY

    • Type
    • Front Load Dryer
    • Capacity
    • 7.4 cu. ft.
    • Matching Washer
    • WM3700HVA
    • Sensor Dry
    • Yes
    • Steam
    • Yes
    • Colors
    • White (W), Graphite Steel (V)

APPEARANCE

    • Intelligent Electronic Controls with LED Display
    • Yes
    • Dial-A-Cycle™
    • Yes
    • Touch Buttons
    • Yes

DRYER PROGRAMS

    • No. of Programs
    • 12
    • Programs
    • Normal, Heavy Duty, Bedding, Anti Bacterial, SteamSanitary™, SteamFresh™, Perm. Press, Delicates, Towels, Speed Dry (Manual Dry), Air Dry (Manual Dry), Downloaded

DRYER OPTIONS

    • No. of Options
    • 12
    • Options
    • More Time, Less Time, Damp Dry Signal, Wrinkle Care, Control Lock, Custom Program, PGM Save, Wi-Fi Connect, Energy Saver, TurboSteam™, Reduce Static, Remote Start
    • Temperature Settings
    • High, Medium High, Medium, Low, Ultra Low
    • Drying Levels
    • Very Dry, More Dry, Normal Dry, Less Dry, Damp Dry
    • Manual Dry Times
    • 60 min., 50 min., 40 min., 30 min., 20 min., More Time/Less Time

FABRIC CARE FEATURES

    • Sensor Dry
    • Yes
    • Precise Temperature Control with Variable Heater
    • Yes
    • Steam
    • TurboSteam™

CONVENIENCE FEATURES

    • 3 Minute Installation Check
    • Yes
    • LoDecibel™ Quiet Operation
    • Yes
    • End of Cycle Signal
    • Yes
    • Drum Light
    • Yes
    • Reversible Door
    • Yes
    • FlowSense™ Duct Clogging Indicator
    • Yes
    • Wrinkle Care Option
    • Yes
    • Child Lock
    • Yes
    • Venting Option
    • 3 Way Venting
    • 4 Adjustable Legs
    • Yes
    • Remaining Time Display/Status Indicator(s)
    • Yes

THINQ® SMART FEATURES

    • SmartDiagnosis™
    • Yes
    • Wi-Fi
    • Yes
    • Remote Start
    • Yes
    • Cycle Monitoring and Notification
    • Yes
    • Energy Monitoring
    • Yes (WiFi)

ENERGY

    • ENERGY STAR® Qualified
    • Yes
    • CEF
    • 3.49

MATERIALS AND FINISHES

    • Aluminized Alloy Steel Drum
    • Yes
    • Tub Rear
    • Painted
    • Cabinet
    • Painted Steel
    • Door
    • Round w/ Chrome trim
    • All Available Colors
    • White (W), Graphite Steel (V)

POWER SOURCE

    • Ratings
    • CSA Listed
    • Electrical Requirements
    • 120V, 15 Amps
    • Type
    • Gas
    • BTU Rating
    • 10,000 Feet

OPTIONS

    • LP Conversion Kit
    • LPK1
    • Side Venting Kit
    • 383EEL9001B
    • Pedestal
    • WDP4V
    • Pedestal (WxHxD)
    • 27" x 14 1/8" x 30 3/4" (50 1/2" D with door open)

DIMENSIONS/CLEARANCES/WEIGHTS

    • Product (WxHxD)
    • 27" x 38 11/16" x 30"
    • Depth with Door Open
    • 51"
    • Carton (WxHxD)
    • 29 19/32” x 43 3/8” x 31 3/8”
    • Weight (Product)
    • 125.7
    • Weight Carton
    • 138.9

WARRANTY

    • Parts & Labor
    • 1 Year

UPC CODES

    • UPC
    •  048231024938

What people are saying

Rated 1 out of 5 by from Horrible Interface & Smart Applicance that Isn't My takeaway from using this machine is that the interface was designed by people who do not actually do laundry. (Was user feedback actually incorporated?) In terms of performance, it doesn't get clothes dry on the only low-heat setting (Delicate"). As a smart appliance it gets low marks because the ThinQ app is of very little utility (although I like the cycle done notification). ~~~ Appliance Issues ~~~ This dryer has an extremely poor, non-intuitive interface. Apparently the interface designers really love pushing buttons. My old dryer I could turn on simply by turning the knob. This one, you have to press the power button and then turn the knob. Maybe not so annoying in itself, but the trend continues... It doesn't remember previous settings for a cycle so I have to go through and press buttons to customize it each time, even if I am using the same cycle as last time. So, for instance, you have to remember to turn on the wrinkle guard each and every time. I wash most of my clothes in cold water and dry them at low temperature so I can combine and minimize my loads. However, this dryer does not actually get clothes dry on the "Delicate" cycle, which is the only one on the dial that uses low heat. (I suspect this is a programming thing and not a sensor thing, but I do not really know. Maybe I just hope it is programming, because that can be fixed through an update if there is a way to get one.) So each time I want to run a load, I have to manually push yet another button multiple times to increase the dryness level to "Very" *every single time*. But that doesn't actually work to get the clothes dry, so instead I have to do the timed dry at low heat (not very energy efficient or convenient). The timed dry is yet another bad interface - totally non-intuitive. You select the time with the setting in the middle of the panel, but you modify the time with buttons on the edge nowhere near that section. (Difficult to find if you are not familiar with the appliance.) It defaults to high temperature, so I have to change that *each time*. It defaults to 40 minutes, so for a full load I need to increase that *each time*. And why is it not on the dial like a normal dryer? I had to look it up in the manual because I wasn't looking on the panel. To make it worse, the control panel is difficult to read at an angle and has small print and poor contrast, so it is difficult to operate when the dryer is against a wall with the panel on the wall-side. It is definitely not good for cramped laundry rooms. ~~~ ThinQ App ~~~ Some of this could be mitigated with the ThinQ app, but it doesn't. You can't make your own selection of downloadable programs or modify existing ones and save them. Really, it should be easy and an obvious thing to do. And what you can modify is extremely limited and doesn't save. (Why can't I select the dry level for "Low Temp Dry"??) Finding a useful pre-set program is difficult and tedious because there isn't a filter or a search beyond the cycle name. (For instance, I would like a filter for cycles/programs that use low temperature.) I can't figure out what the "Remote Start" feature is supposed to do, since it forgets the setting once the dryer is off. (And it is a press and hold to turn on, which makes it annoying to do each time.) The scenarios I can think of where this would be a useful feature won't work. Maybe run a timed cycle because I know the load won't be dry when the cycle is done? No - currently, there is no timed cycle option in the app. Maybe because the kids loaded the dryer for me? No, because the Remote Start setting doesn't save, and they won't remember to turn on the machine and set it each time. The main use of the app for me is the notification of when the dryer is cycle done (which I really like). It's really a shame the app is so useless. Wouldn't it be cool to have maybe three or four favorite cycles (complete with custom mods) that you could just select from your smart watch while standing in front of your machine after loading it? (Or, I suppose, phone, but I don't want to - and I shouldn't have to - carry my phone around the house everywhere.) It would be even better if I could modify and download those 3 or 4 programs to those unused places on the dial. ~~~ One (Somewhat) Bright Spot ~~~ The only saving grace to all this is that you get one saved favorite and one ThinQ-app downloaded cycle. Of course, since you cannot modify the downloaded settings, if the exact one you need does not exist that doesn't help. And, if you or somebody in your house downloads a different cycle, to use your customary one you need to get your phone, start up the app, find the program (hopefully marked as a favorite to make it easier), and download it again. ~~~ Summary: Not Recommended ~~~ Truly, my blood pressure goes up nearly every time I use this dryer. I really regret buying it and cannot recommend it to anybody. (So much for research.)
Date published: 2020-03-30
Rated 4 out of 5 by from Nice Features and Performance I am happy with the dryer's performance, but I'm still unsure about the settings . The manual is not very specific as to which settings to use and how to make time, temperature and dryness level adjustments. For example, removing wrinkles from line dried items for less than 20 minutes does not seem possible. Overall, I would recommend the product but would caution a shopper to make sure he or she understands the various selections and other uses.
Date published: 2020-03-29
Rated 5 out of 5 by from no wrinkles My old dryer was about 12 years old and had no idea that a new one would be so much better. after all they just dry out clothes don't they? Well not this new LG washer is so much better. all my golf shirts come out ready to wear, no more ironing
Date published: 2020-03-27
  • y_2020, m_10, d_28, h_16
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_217
  • loc_en_US, sid_MD05981698, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 2ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

My dryer is not getting hot I’ve been on hold wit lG for 40 min is there anything I can do myself to fix it

Asked by: Cocoachanel
I had the same issue with my dryer and the reason it was not getting hot was that the ducts were clogged with lint and until I cleaned them out, the dryer would not get hot. You can check to see if your ducts are clogged to see if they need cleaning. The ENERGY STAR® Qualified LG 7.4 cu. ft. Ultra Large Capacity Smart wi-fi Enabled SteamDryer™, Model # DLGX3701W has a Flow Sense™ duct blockage sensing system that detects and alerts you to restrictions in the installed household ductwork that reduce exhaust airflow through the dryer. If you see the alert: Clean or repair the ducts to remove the restrictions. Keeping your ducts clean helps increase efficiency and reduce long drying times caused by blocked ducts. Page 27 of your installation manual has explicit instructions for how to use the Flow Sense™ duct blockage sensing system. If you need another copy of the owner's manual, please visit us at https://www.lg.com/us/support/product/lg-DLGX3701V.ASSEEUS where you can download and printout a PDF copy of the owner's manual...^IFV
Answered by: Ivanf
Date published: 2020-10-02

I need a 90 degree dryer elbow vent for this unit. What would work for this dryer?

Asked by: lowkey
Use only 4-inch (10.2 cm) rigid, semi-rigid or flexible metal ductwork inside the dryer cabinet and for venting outside. To reduce the risk of fire, combustion, or accumulation of combustible gases, DO NOT exhaust dryer air into an enclosed and unventilated area, such as an attic, wall, ceiling, crawl space, chimney, gas vent, or concealed space of a building. To reduce the risk of fire, DO NOT exhaust the dryer with plastic or thin foil ducting.The exhaust duct must be 4-inch (10.2 cm) in diameter with no obstructions. The exhaust duct should be kept as short as possible. Make sure to clean any old ducts before installing your new dryer. Rigid, semi-rigid or flexible metal ducting is recommended for use between the dryer and the wall. All non-rigid metal transition duct must be UL-listed. Use of other materials for transition duct could affect drying time. DO NOT use sheet metal screws or other fasteners which extend into the duct that could catch lint and reduce the efficiency of the exhaust system. Secure all joints with duct tape.
Answered by: ChrisPSM
Date published: 2020-03-10

When looking at it from the front, can DLGX3701 vent through the right side panel? I see a knock-out in the metal on both the right and left side.

Asked by: DIY SS
Right-side venting is not available on the ENERGY STAR® Qualified LG 7.4 cu. ft. Ultra Large Capacity Smart Wi-Fi Enabled SteamDryer™, Model # DLGX3701W or on our Gas Dryers (that would be the left-side if standing in front of the dryer)...^IFV
Answered by: Ivanf
Date published: 2020-03-05

Does the DLGX3701 dryer have a stainless interior?  Also can it be converted to LP gas?

Asked by: TeriC
The ENERGY STAR® Qualified LG 7.4 cu. ft. Ultra Large Capacity Smart wi-fi Enabled SteamDryer™, Model # DLGX3701W has an Aluminized Alloy Steel Drum. For the LP Conversion Kit order part number 383EEL3002D...^IFV
Answered by: Ivanf
Date published: 2020-01-20

I want to replace my LG dlg2526w with the dlgx3701w. I have the pedestal model wdp3w. Can I use that with the dlgx3710w?

Asked by: Jawblahblah
Yes, the WDP3W is compatible with the DLGX3701W.
Answered by: ChrisPSM
Date published: 2020-01-03

I have a tight closet, will this appliance fit in a closet with a depth of 35inches?

Asked by: CitySlicker19
The ENERGY STAR® Qualified LG 7.4 cu. ft. Ultra Large Capacity Smart wi-fi Enabled SteamDryer™, Model # DLGX3701V has a depth of 30" and the recommended installation clearance spacing for the rear is 5"...^IFV
Answered by: Ivanf
Date published: 2020-01-29

Is this model compatible with the WDP3W pedestal?

Asked by: Mark45
You can install the 27" LG Laundry Pedestal, Model # WDP3W under the ENERGY STAR® Qualified LG 7.4 cu. ft. Ultra Large Capacity Smart wi-fi Enabled SteamDryer™, Model # DLGX3701W...^IFV
Answered by: Ivanf
Date published: 2019-11-07

DLGX3701W Gas Dryer. How does the exhaust gas vent? Does the 'exhaust gases' vent through the clothes dryer vent or does this gas dryer require a separate natural gas exhaust vent?

Asked by: Endo27
The ENERGY STAR® Qualified LG 7.4 cu. ft. Ultra Large Capacity Smart wi-fi Enabled SteamDryer™, Model # DLGX3701W has to be connected to a vent duct so the lint and any excess gasses in the dryer escape to the outside of your home. That is why it is important for the dryer to be vented properly to an outside location, and the vent hose must be a flexible or rigid metal pipe and not a nonmetallic flexible hose...^IFV
Answered by: Ivanf
Date published: 2019-10-23
