DLGY1202V
7.3 cu. ft. Ultra Large Capacity Dryer with Front Control Design and SteamFresh™ Cycle
  • Ultra Large 7.3 cu. ft. Capacity
  • Front Control Design
  • SteamFresh™ Cycle
  • Smart Diagnosis™
7.3 cu. ft. Ultra Large Capacity Dryer with Front Control Design and SteamFresh™ Cycle

SUMMARY

  • Dryer Type
    Gas
    SteamDryer™
    Yes

CAPACITY

  • Capacity
    7.3 cu. ft.

APPEARANCE

  • Design Look
    Front Control
    Front Electronic Control Panel with LED Display
    Yes

DRYING PROGRAMS

  • Programs (Sensor Dry)
    Cotton/Normal, Perm. Press/Casual, Heavy Duty, Small Load, Bulky/Bedding, Anti-Bacterial, Towels, Delicates, SteamFresh™, Wrinkle Free
    Programs (Manual Dry)
    Speed Dry, Air Dry
  • No. of Options
    7
    Options
    More Time, Less Time, Wrinkle Care, Custom Program, Child Lock, Damp Dry Signal, End of Cycle Signal
  • Temperature Settings
    High, Medium High, Medium, Low, Ultra Low
    Drying Levels
    Very Dry, More Dry, Normal Dry, Less Dry, Damp Dry
  • Manual Dry Times
    60 min., 50 min., 40 min., 30 min., 20 min., More Time/Less Time

FABRIC CARE FEATURES

  • SteamFresh™ Cycle
    Yes
    Wrinkle Free Cycle
    Yes
  • Sensor Dry
    Yes
    Precise Temperature Control with Variable Heater
    Yes

CONVENIENCE FEATURES

  • LoDecibel™ Quiet Operation
    Yes
    SmartDiagnosis™
    Yes
  • FlowSense™ Duct Clogging Indicator
    Yes
    Anti-Bacterial Cycle
    Yes
  • Wrinkle Care Option
    Yes
    Remaining Time Display/Status Indicator(s)
    Yes
  • End of Cycle Signal
    Yes
    Child Lock
    Yes
  • 3 Minute Installation Check
    Yes
    Drum Light
    Yes
  • Venting Option
    3 Way Venting
    Leveling Legs
    4 Adjustable Legs
  • Reversible Door
    Yes

MATERIALS AND FINISHES

  • Aluminized Alloy Steel Drum
    Yes
    Top Plate
    Plastic
  • Cabinet
    Painted Steel
    Control Panel
    Plastic
  • Chrome Edged Diamond Glass Door
    Yes
    Available Colors
    White (W), Graphite Steel (V)

POWER SOURCE

  • Ratings
    CSA Listed
    Electrical Requirements
    120V, 15 Amps
  • Type
    Gas

OPTIONS

  • Dryer Rack
    3750EL0001C
    LP Conversion Kit
    4948EL4002B
  • Side Venting Kit
    3911EZ9131X

DIMENSIONS

  • Product (WxHxD)
    27" x 40 5/32" x 28 3/8" (50 1/4" D with door open)
    Carton (WxHxD)
    29 1/2" x 43 7/10" x 31 1/4"
  • Weight (Product/Carton)
    125.4 lbs. / 143.3 lbs.

Warranty/UPC

  • Limited Warranty
    1 Year Parts and Labor
    UPC
    048231013383
What people are saying
Rated 5 out of 5 by from Everything fits Purchased and installed this dryer and matching washer over 2 years ago. It has been used constantly and it works perfectly. I am selling my home and I am looking to purchase it again. When my son and wife visit, they always brings mountains of laundry. Sometimes I think the washer and dryer are the main reason for their visit. The 7.3 cu capacity is more tan enough room for bath sheets and king size quilts. I couldn't be more pleased with the product
Date published: 2017-02-09
Rated 5 out of 5 by from Love Everything About This Dryer Purchased about a month ago - can't say enough good things about the dryer - beautiful looking and performing great. Clothes come out perfect, love the wrinkle free steam setting too. Couldn't be happier with my purchase.
Date published: 2015-06-09
Rated 5 out of 5 by from I love my new dryer! What a great dryer! It's quiet, dries more quickly than my old gas dryer, and the front load makes it easy to get everything in and out. Many cycles to choose from, and I love the sleek design and color. Decent value for the quality. I highly recommend it.
Date published: 2015-04-29
  • y_2019, m_7, d_14, h_18
  • bvseo_bulk, prod_bvrr, vn_bulk_2.0.12
  • cp_1, bvpage1
  • co_hasreviews, tv_1, tr_36
  • loc_en_US, sid_MD05036640, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 185ms
  • REVIEWS, PRODUCT
ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

Is there a reset button on dryer Model #DLEY1201

Asked by: Char2665
The LG 7.3 cu. ft. Ultra Large Capacity Dryer with Front Control Design and SteamFresh™ Cycle, Model # DLEY1201V does not have a reset button on it. A Hard reset can be done by unplugging the dryer and pressing and holding the POWER/START button for 5 seconds then pressing and holding down the PLAY/PAUSE button for 5 seconds. When you plug the unit back in, check to see if the power light and the unit come back on. If the unit does not power on, it will require a repair service...^IFV
Answered by: LGJoel
Date published: 2018-06-06

Hi, how many pounds this dry model machine can dry ?

Asked by: Kelen
This dryer is 7.3 cu. ft. With different dimensions and weight of clothing providing a weight of clothing cannot be estimated. ^CP
Answered by: ChrisPSM
Date published: 2017-12-21

Hello, My dryer (DLGY1202V) spins anytime the door is shut. The only time the drum will stop spinning is when the door is open and the door switch is not engaged. This even happens when I have not pressed the power button.  What should I do?

Asked by: Glane
We regret the trouble you have experienced with this Dryer. From the issue described, the unit will likely require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2017-08-10

Dryer keeps shutting it's self off and flashing end before the items in it are dry. What should I do?

Asked by: Tammy91
Hi Tammy91. We regret to read about the issues that you are experiencing with your LG 7.3 cu. ft. Ultra Large Capacity Dryer with Front Control Design and SteamFresh™ Cycle, Model # DLGY1202V and apologize for any inconveniences. Typically, when the dryer malfunctions, it will flash an error code on the display that indicates what the problem is. Look to see if there is an error code showing and make note of it as that would help to diagnose the problem. This dryer also has a FlowSense™ Duct Clogging Indicator which indicates the amount of restriction in the drying system and can distinguish between a restricted exhaust duct and a restricted lint filter. This feature can be activated only on the Heavy Duty, Towels, Cotton/Normal, and Time Dry cycles if the temperature is set to medium or high. Your manual has instructions on how to activate this feature. If zero bars show on your display, then your exhaust duct is in good condition and the dryer will perform with high efficiency and the shortest possible drying times. If 2 bars are showing, the exhaust system will need to be examined for lint build up or other restrictions. Those restrictions can result in longer drying times and reduced drying efficiency. The exhaust duct may need to be cleaned or repaired. A four bar display indicates that the exhaust duct is inadequate for normal operation of the dryer. Your dryer also features SmartDiagnosis™ technology which helps to diagnose and solve any problems that you encounter quickly and correctly. With the addition of the SmartDiagnosis™ App, the problems can be diagnosed without having to call an LG representative. The application records and analyzes the special tones emitted by your dryer to instantly provide troubleshooting steps to get the problem fixed. This app is available for iPhone and Android smart phones and if you do not have either, you can then contact LG Customer Service at (800) 243-0000 and a representative will assist you in running the SmartDiagnosis™ test over the phone...^IFV
Answered by: LGJoel
Date published: 2016-12-07

Where can i get a replacement lint filter?

Asked by: Frigid
Hello , You can call our customer service line to make that request at 877-543-8325.
Answered by: NeilE
Date published: 2016-05-18

how do I put the dryer on high?

Asked by: nale
We appreciate your interest in this dryer. . The temperature setting depends on the cycle you select. For more information on the cycles please refer to page 31 of your owner's manual.
Answered by: ShenaS
Date published: 2016-04-29

My dryer won't turn on I unplugged and plugged it back on and it won't work help please !!

Asked by: Mr USA
We regret the trouble you have experienced with this Gas Dryer. It is suggested to check the circuit breaker box to be certain that the device has power. If this does not resolve the matter, then the dryer may require service. To make service arrangements, you may either contact our Customer Interactive Center at 800-243-0000, or you can check our Repair Provider Lookup on our website, at http://www.lg.com/us/support/repair/support-repair-provider-lookup.jsp.
Answered by: NeilE
Date published: 2016-02-23

Hello, I have this model in white, brand new. I just recently put a shirt and started the steam fresh cycle. After the cycle was completed my shirt was soaked. What could be the problem?

Asked by: Gdelatorre
We regret the trouble you are having with the Steam Fresh cycle on your unit. During this cycle the clothes will be sprayed with hot water and come out feeling damp or wet. The Steam Fresh cycle uses steam only to reduce winkles and odors from fabrics. You can find more information on each cycle setting on page 31 of your owner’s manual. You may also contact our Customer Interactive Center at 800-243-0000 for more assistance.
Answered by: ShenaS
Date published: 2016-02-11
