Discontinued
LFXC22596M
22 cu. ft. Smart wi-fi Enabled InstaView™ Door-in-Door® Counter-Depth Refrigerator
  • 22 cu. ft. Capacity
  • Counter-Depth
  • InstaView™ Door-in-Door®
  • Dual Ice Makers
  • PrintProof™ Finish
  • SmartThinQ® Technology
22 cu. ft. Smart wi-fi Enabled InstaView™ Door-in-Door® Counter-Depth Refrigerator

SUMMARY

  • Door Type
    French 3-Door
    Refrigerator Type
    InstaView™ Door-in-Door®
  • SmartThinQ®
    Yes
    wi-fi Enabled
    Yes
  • Total Capacity
    21.9
    Counter Depth (in.)
    Yes
  • Ice & Water Dispenser
    Yes
    Door Cooling+
    Yes
  • ENERGY STAR® Qualified
    Yes

CAPACITY

  • Refrigerator (cu.ft.)
    14.60
    Freezer (cu.ft.)
    7.30
  • Total (cu.ft.)
    21.9

ENERGY

  • Energy Consumption (kWh/Year)
    664
    ENERGY STAR® Qualified
    Yes

WATER & ICE SYSTEM

  • Ice & Water Dispenser
    Yes
    Dispenser Type
    Integrated Tall Ice & Water Dispenser
  • Daily Ice Production (lbs)
    6.0 lbs
    IcePlus™ Production (lbs)
    6.5 lbs.
  • Ice Storage Capacity (lbs)
    2.5 + 4.0 lbs
    Ice System
    Slim SpacePlus®
  • Dual Ice
    Yes
    Dispenser Light
    Yes
  • Water Filter
    LT1000P

COOLING

  • Linear Compressor
    Yes
    Smart Cooling™ System
    Yes
  • Multi-Air Flow Cooling
    Yes
    Temperature Sensors
    6
  • Fresh Air Filter
    Yes
    Evaporator
    Yes

CONVENIENCE

  • Display Type
    Membrane/White LED
    Temperature Controls
    Electronic/Digital
  • Door Alarm
    Yes
    Child Lock
    Yes
  • Auto Closing Door Hinge
    Yes
    Sabbath Mode
    Yes
  • LoDecibel™ Quiet Operation
    Yes

REFRIGERATOR

  • No. of Shelves
    4 Split
    Cantilevered Shelves
    Hybrid Cantilevered
  • Shelf Construction
    Spill Protector™ Tempered Glass
    Crisper Bins
    2 Humidity Crispers
  • Glide N’ Serve™ Drawer
    Yes
    Refrigerator Light
    Ceiling LED (Frameless)

REFRIGERATOR DOOR

  • InstaView™ Door-in-Door®
    Yes
    Door-In-Door® with ColdSaver™ Panel
    Yes
  • No. of Bins
    7 Total (Including Door-in-Door®)
    Door Bin Construction
    1 Piece (Clear)

FREEZER

  • Door Type
    Pull Drawer
    Drawers
    2-Tier Organization
  • DuraBase™ Solid Drawer Base
    Yes
    Drawer Divider
    Yes
  • Freezer Light
    LED Lighting
    Freezer Handle
    SmartPull™ Handle

SMARTTHINQ® SMART FEATURES

  • wi-fi Enabled
    Yes
    Works with
    Google Assistant and Amazon Alexa
  • SmartDiagnosis™
    Yes

MATERIALS AND FINISHES

  • Contour Door
    Yes
    Hidden Hinges
    Yes
  • Fingerprint & Smudge Resistant Exterior
    Yes
    Handles
    Matching Commercial Handles
  • All Available Colors
    PrintProof™ Stainless Steel, PrintProof™ Matte Black Stainless Steel, PrintProof™ Black Stainless Steel

DIMENSIONS / CLEARANCES / WEIGHTS

  • Depth with Handles
    31 1/4"
    Depth without Handles
    28 3/4"
  • Depth without Door
    24 3/4"
    Depth (Total with Door Open)
    43 1/2"
  • Height to Top of Case
    68 3/8"
    Height to Top of Door Hinge
    69 3/4"
  • Width
    35 3/4"
    Width (Door Open 90˚ with Handle)
    44 1/4"
  • Width (Door Open 90˚ without Handle)
    39 1/4"
    Door Edge Clearance with Handle
    4 1/2"
  • Door Edge Clearance without Handle
    1 1/3"
    Installation Clearance
    Sides 1/8", Top 1", Back 2"
  • Weight (Unit/Carton)
    289 lbs./319 lbs.
    Carton Dimensions (WxHxD)
    38" x 73" x 36"

LIMITED WARRANTY

  • Parts & Labor
    1 Year
    Sealed System (Parts & Labor)
    5 Years
  • Compressor (Parts & Labor)
    5 Years
    Linear Compressor (Parts Only)
    6-10 Years

UPC CODES

  • UPC
    048231797221

What people are saying

Rated 4 out of 5 by from Love the door in door feature We have had our refrigerator about 3 weeks. We like the view door in door feature. It makes getting those tasty beverages quick and easy The refrigerator fits quite a bit, even the counter depth that we purchased. Still getting used to the freezer on the bottom. Our water dispenser is reallllly slow. According to LG it should take 3 to 8 seconds to fill a 7 oz cup. Ours is currently taking more than 30 seconds. We have someone coming to see if the installer screwed up. I hope so, because otherwise that is a useless feature. If the water dispenser gets fixed, then I’d give it 5 stars
Date published: 2020-01-07
Rated 5 out of 5 by from Great Features plenty of room! We love the fridge! The quick access door, and the refrigerators capacity!
Date published: 2019-12-25
Rated 5 out of 5 by from Great features. Love the front door. I bought this for my new house. I love the color and the extra ice In the freezer, especially during the holidays.
Date published: 2019-12-24
  • y_2020, m_1, d_16, h_14
  • bvseo_bulk, prod_bvrr, vn_bulk_3.0.4
  • cp_1, bvpage1
  • co_hasreviews, tv_0, tr_36
  • loc_en_US, sid_MD06020416, prod, sort_[SortEntry(order=SUBMISSION_TIME, direction=DESCENDING)]
  • clientName_lg
  • bvseo_sdk, java_sdk, bvseo-4.0.0
  • CLOUD, getReviews, 254ms
  • REVIEWS, PRODUCT

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

Doe this refrigerator LFXC22596D make craft ice.

Asked by: Dundo
No, the LFXC22596D features Dual ice makers, dispensed from the door and located in the freezer compartment, produces large amounts of ice so you never run out. This extra ice storage helps ensure that you have extra ice on hand for those hot summer days or when entertaining large parties. However neither ice maker produces craft ice. You can find information about our refrigerators that produce craft ice via the following link: https://www.lg.com/us/discover/instaview-door-in-door/craft-ice
Answered by: ChrisPSM
Date published: 2019-11-06

Is this model available in a 21 cube feet

Asked by: Pickle 70
The actual capacity for the ENERGY STAR® Qualified LG 22 cu. ft. Smart wi-fi Enabled InstaView™ Door-in-Door® Counter-Depth Refrigerator, Model # LFXC22596D is 21.9 cubic feet, 14.6 cubic feet for the Refrigerator compartment and 7.3 cubic feet for the freezer compartment...^IFV
Answered by: Ivanf
Date published: 2019-09-12

Are the door handles the same style on this LG model as the stainless steel LG Studio (model LSFXC2496S)?

Asked by: DS24
The doors for the refrigerator compartment on the ENERGY STAR® Qualified LG 22 cu. ft. Smart wi-fi Enabled InstaView™ Door-in-Door® Counter-Depth Refrigerator, Model # LFXC22596S are Matching CommercialHandles & the handle on the Freezer Compartment is a SmartPull™ Handle and Model # LSFXC2496S has LG Studio Style Handles for the refrigerator compartment & a Pull Drawer for the Freezer compartment so they don't have the same handles...^IFV
Answered by: Ivanf
Date published: 2019-08-20

If the refrigerator doors are open, will the water/ice dispenser work at the same time?

Asked by: Lisa614
The dispenser on the ENERGY STAR® Qualified LG 22 cu. ft. Smart wi-fi Enabled InstaView™ Door-in-Door® Counter-Depth Refrigerator, Model # LFXC22596S will not operate when either of the refrigerator doors is open...^IFV
Answered by: Ivanf
Date published: 2019-07-15

Do you make any side by side freezer on the bottom refrigerators that are under 67.5" tall?

Asked by: Tazzer22
Hi Tazzer22. Our Side-by-Side Refrigerators and Bottom Freezer Refrigerators are two separate categories. The Side-by-Side Refrigerators have a freezer compartment that is side-by-side with the refrigerator compartment as the name implies and our Bottom Freezer models have the freezer compartment below the refrigerator compartment. Which type of refrigerator were you interested in finding out about with regards to the height?...^IFV
Answered by: Ivanf
Date published: 2019-07-12

What is the depth of the LFXC22596D?  Thanks

Asked by: RBTjr
The ENERGY STAR® Qualified LG 22 cu. ft. Smart wi-fi Enabled InstaView™ Door-in-Door® Counter-Depth Refrigerator, Model # LFXC22596D has a depth of 31 1/4" with the handles, 28 3/4" without the handles, and 43 1/2" with the door open...^IFV
Answered by: Ivanf
Date published: 2019-07-09

The door of the fridge has scratched. What’s the best way to remove the scratch safely?

Asked by: Hemk
Hello, you can use Bar Keepers Friend Soft Cleanser, however, depending on the depth of the scratch it may not be repairable. ^AC
Answered by: Amber C
Date published: 2019-02-01

My wife was cleaning the refrigerator and the glass shelf that is on top of the crispers shattered into a billion pieces. I need to replace the shelf. Where do I go on the computer to order the piece. Model number: LFX28977ST/00

Asked by: Fisherdoc
To order parts, please see the following. ^AC Encompass Parts Distribution: Sales: 866-779-7906 or https://lg.encompass.com
Answered by: Amber C
Date published: 2019-01-07
