LSXC22436S
22 cu. ft. Smart wi-fi Enabled Side-by-Side Counter-Depth Refrigerator
$2,099.99
Where to Buy
CompareAdd to CompareRemove Compare
  • 22 cu. ft. Capacity
  • SmartThinQ® Technology
  • Counter-Depth
  • 4 Tempered Glass Shelves
  • 4 Refrigerator Door Bins
  • SpacePlus® Ice System
22 cu. ft. Smart wi-fi Enabled Side-by-Side Counter-Depth Refrigerator
$ 2,099.99
Where to Buy
This model you are viewing is no longer available.1

This model you are viewing is no longer available.

Click below to see similar products in this category that are available now.
See Available Products
Download Spec Sheet Download Energy Guide
Close

SUMMARY

  • Door Type
    Side-by-Side
    SmartThinQ®
    Yes
  • wi-fi Enabled
    Yes
    Total Capacity
    21.9
  • Ice & Water Dispenser
    Yes
    ENERGY STAR® Qualified
    Yes
  • Counter Depth (in.)
    Yes
    SmartDiagnosis™
    Yes

REFRIGERATOR

  • No. of Shelves
    4
    No. of Door Bins
    4
  • Shelf Construction
    Tempered Glass
    Crisper Bins
    2
  • Refrigerator Light
    Ceiling LED

REFRIGERATOR DOOR

  • Door Bin Construction
    1 Piece (Clear)

FREEZER

  • Drawers
    2 Drawer/3 Shelves
    Ice Bin
    Icemaker & Ice bin in Door
  • Door Bins
    3 / 1 Piece(Clear)
    Door Type
    Side Swing
  • Handle
    Matching Commercial Handles

DIMENSIONS/CLEARANCES/WEIGHT

  • Depth with Handles
    31 13/16"
    Depth without Handles
    29 3/8"
  • Depth without Door
    24 10/16"
    Depth (Total with Door Open)
    46 5/8"
  • Height to Top of Case
    69 11/32"
    Height to Top of Door Hinge
    70 5/16"
  • Width
    35 7/8"
    Width (Door Open 90˚ with Handle)
    44 5/16"
  • Width (Door Open 90˚ without Handle)
    39 5/8"
    Door Edge Clearance with Handle
    1 3/8"
  • Door Edge Clearance without Handle
    5/16"
    Installation Clearance
    Sides 1/8", Top 1", Back 2"
  • Weight (Unit/Carton)
    280 lbs / 304 lbs
    Carton Dimensions (WxHxD)
    38" x 72 5/9" x 33"

MATERIALS & FINISHES

  • Available Colors
    Stainless Steel
    Hidden Hinges
    Yes
  • Surface
    Smooth
    Contour Door
    Yes

CAPACITY

  • Refrigerator
    14.51 cu. ft.
    Freezer
    7.40 cu. ft.
  • Total
    21.9 cu. ft.

RATINGS

  • Energy Consumption
    520
    CEE Tier
    3

CONVENIENCE

  • Temperature Controls
    Electronic/Digital
    Door Alarm
    Yes
  • Auto Closing Door Hinge
    Yes (Cam Hinge Type)
    Child Lock
    Yes
  • Display Type
    Membrane (Green LED)

WATER & ICE SYSTEM

  • Ice System
    SpacePlus®
    Ice & Water Dispenser
    Yes
  • Dispenser Type
    Integrated Tall Ice & Water Dispenser
    Daily Ice Production (lbs)
    3.5 lbs
  • IcePlus™ Production (lbs)
    4.1 lbs
    Ice Storage Capacity (lbs)
    4.5 lbs
  • Dispenser Light
    Yes
    Water Filter
    LT1000P

COOLING

  • Linear Compressor
    Yes
    Multi-Air Flow
    Yes
  • Temperature Sensors
    5

SMARTTHINQ®

  • Wi-Fi
    Yes
    SmartDiagnosis™
    Yes
  • Voice Activation
    Yes
    Works with
    Google Assistant and Amazon Alexa
  • Smart Grid Ready
    Yes

WARRANTY

  • UPC
    048231788823
    Parts & Labor
    1 Year
  • Sealed System (Parts & Labor)
    5 Years
    Compressor (Parts & Labor)
    5 Years
  • Linear Compressor (Parts Only)
    6-10 Years

ASK & ANSWER

Ask your questions. Share your answers.
Please review the detailed product information and help guides in the
Product Support section for this product prior to posting a question.

how many amps?

Asked by: bobbiM
The ENERGY STAR® Qualified LG 22 cu. ft. Smart wi-fi Enabled Side-by-Side Counter-Depth Refrigerator, Model # LSXC22436S has to be plugged into its own individual grounded outlet rated at 115 V ~ 60 Hz and fused at 15 A or 127 V ~ 60 Hz and fused at 15 A. Actual voltage will be 120V...^IFV
Answered by: Ivanf
Date published: 2019-08-12

I can get water to dispenser but not to ice maker , why

Asked by: Rankin62
Please refer to the following help library article for issues with the ice maker not producing ice: http://www.lg.com/us/support/product-help/CT10000021-1400773605181-no-ice ^CP
Answered by: ChrisPSM
Date published: 2019-03-14

Want a stainless side by side 33” wide, finger print resistant ?

Asked by: Tom Eastman
Regrettably, we do not have any Side-by-Side Refrigerators that have a width of 33". They only come in widths of 36" (Actual 35 7/8") or 42"...^IFV
Answered by: LGJoel
Date published: 2018-12-03

When will this model be available for the US? If I order, what would the realistic ETA? Ordered the previous model and after 2 months of waiting my order was cancelled b/c it was discontinued. Want to wait if can for the replacement model - need soon.
