24 cu. ft. Top Mount Refrigerator

1/4
Logo Image
1/4
LG Logo
Product
24 cu. ft. Top Mount Refrigerator
24 cu. ft. Top Mount Refrigerator
24 cu. ft. Top Mount Refrigerator
DISCONTINUED
24 cu. ft. Top Mount Refrigerator

24 cu. ft. Top Mount Refrigerator

LTCS24223W

Key features

  • 24 cu. ft. Capacity
  • Contoured Doors with Pocket Handles
  • Full Width Pantry Drawer
  • Factory Installed Ice Maker
  • Rated Energy Star Most Efficient 2020

Specifications

Download Spec Sheetdownload-guide iconDownload Energy Guide
  • FREEZER
  • MATERIALS & FINISHES
  • REFRIGERATOR DOOR
  • DIMENSIONS/CLEARANCES/WEIGHT
  • CAPACITY
  • FEATURES
  • WARRANTY
  • REFRIGERATOR
  • SUMMARY
  • COOLING
  • RATINGS
  • See All
  • FREEZER
    Freezer Light
    Premium LED
    Ice Bin
    Yes
    Shelf Construction
    Tempered Glass
    Auto Defrost
    Yes
    No. of Shelves
    1
    No. of Door Bins/Shelves
    2
    Ice Maker
    Yes
    FREEZER
    Freezer Light
    Premium LED
    Ice Bin
    Yes
    Shelf Construction
    Tempered Glass
    Auto Defrost
    Yes
    No. of Shelves
    1
    No. of Door Bins/Shelves
    2
    Ice Maker
    Yes
    MATERIALS & FINISHES
    Available Colors
    Smooth White (SW), Smooth Black (SB), Stainless Steel (ST)
    Back
    Flush & Metal cover over mechanical parts
    Contour Door
    Yes
    Surface
    Coated Metal, Stainless Steel
    Reversible Door
    yes
    Blowing Agent
    Cyclopentane - Low Global Warming Potential, and Zero Ozone Depletion Potential Blowing Agent
    REFRIGERATOR DOOR
    Tall Item Retainer
    Yes
    Dairy BIn
    Yes
    No. of Door Bins
    3 (2 Gallon Sized)
    DIMENSIONS/CLEARANCES/WEIGHT
    Width
    32 3/4"
    Weight (Unit/Carton)
    224 lbs./248 lbs.
    Depth (Total with Door Open)
    63"
    Depth Including Door
    33 3/8"
    Height to Top of Case
    67 7/8"
    Width (Door Open 90˚ with Handle)
    34 3/4"
    Carton Dimensions (WxHxD)
    34 4/5" x 71 3/7" x 38 1/7"
    Installation Clearance
    2"
    Dimensions (W case x H top of hinge x D with handles)
    32 3/4" x 68 1/2" x 33 3/8"
    Depth without Door
    29"
    Height to Top of Door Hinge
    70 1/4"
    Width (Door Open 90˚ without Handle)
    34 3/4"
    CAPACITY
    Freezer
    6.2 cu. ft.
    Total
    23.8 cu. ft.
    Refrigerator
    17.60 cu. ft.
    FEATURES
    ENERGY STAR® Qualified
    Yes (501 kWh/Year)
    Temperature Sensors
    Yes
    LoDecibel™ Operation
    Yes
    Freezer Door Type
    Top Swing Door
    Temperature Controls
    Digital
    Display
    Internal Membrane / Green LED
    Energy Rating
    ENERGY STAR® Qualified
    Linear Compressor
    Inverter
    WARRANTY
    Limited Warranty
    1 Year Parts and Labor, 5 Years on the Sealed System (Parts & Labor), 5 Years on the Compressor (Parts & Labor), 6-10 Years on Linear Compressor (Parts Only)
    UPC
    048231786997
    REFRIGERATOR
    Refrigerator Light
    Premium LED
    No. of Shelves
    2 Full
    Crisper Bins
    2-Humidity Crispers
    Full Width Pantry Drawer
    Yes
    Dairy Corner/Bin
    1
    Multi-Air Flow Cooling
    Yes
    Shelf Construction
    Tempered Glass
    Gallon Storage
    2 Gallons
    Daily Ice Production
    3.7 lbs
    Full Snack Tray/2 Bottle Guides
    Yes
    Ice Storage Capacity
    5.5 lbs
    Temperature Sensors
    4
    Compressor Type
    Inverter
    SUMMARY
    ENERGY STAR® Qualified
    Yes
    Total Capacity
    23.8
    Standard Depth
    Yes
    SmartDiagnosis™
    Yes
    COOLING
    Refrigerant
    R600a: Low Global Warming Potential, Zero Ozone Depletion Potential and More Energy Efficient Refrigerant than R134a
    RATINGS
    Energy Consumption
    438kWh
    Amps
    20 Amp
    Requirements
    120V, 60Hz, 15 Amp
