New High Haze UHD Standard Signage

75UH5J-M

Key Features

Brightness (Typ.) : 500 nit
Surface Treatement (Haze) : 28%
Bezel : 14.9 mm (Even bezel)
Depth : 57.9 mm
Interface : HDMI(3) / DP / DVI-D / USB 2.0 / RS232C / RJ45 / Audio / IR
Built-in Speaker

A screen showing the meeting’s contents is installed on the meeting room’s wall.

* All images in this web page are for illustrative purposes only.

75UH5J-M has a brightness of 500 nits, so it is clearly visible, even under strong light.

Adequate Brightness Level

The 75UH5J-M series boasts an adequate brightness level of 500 cd/m² for indoor displays, effectively showcasing content and capturing the public’s attention. This makes it an adequate display solution for marketing purposes in various settings, including meeting rooms, airports, retail outlets, and shopping malls.

* Actual images available may differ from the example images shown.

A number of tasks can be done at the same time with the intuitive GUI.

High-Performance with webOS

LG webOS platform enhances user convenience with intuitive GUI and simple app development tools.

Conformal Coating

In various places the 75UH5J-M series is unable to avoid exposure to environments containing dust, humidity, etc. which may hamper performance over time. The conformal coating on power board reduces these risks by protecting 75UH5J-M series from salt, dust, iron powder, humidity, etc.

* Actual images (signage display) available may differ from the example images shown.

Mobile Content Management

You can create a store profile and get template recommendations using the Promota* app. Users can customize templates as needed and easily create and manage content not only on PCs but also on mobile devices.

In a clothing store, a user is using the app to produce promotional content to display on the UH5J-H installed on the store’s wall.

* LG Promota is can be downloaded from the App Store and Google Play store. (Not available for Europe/CIS Region)
* In Korea, the name is not Promota, but Mustard.

IP5x Certified Design

The IP5x Dust-Proof Certification ensures that the product is protected from dust, reducing the risk of performance degradation.

Compatible with AV Control System

The 75UH5J-M series has supported Crestron Connected® for high compatibility with professional AV controls to achieve seamless integration and automated control*, boosting business management efficiency.

* Network based control

All Spec

PANEL

Screen Size (Inch)
75 inches
Panel Technology
IPS technology
Back Light Type
Edge
Aspect Ratio
16:9
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
120 Hz
Brightness
500nit (Typ.)
Contrast Ratio
1,100:1
Dynamic CR
1,000,000:1
Color Gamut
BT709 95%
Viewing Angle (H x V)
178º x 178º
Color Depth (Number of Colors)
1.07 billion
Response Time
6ms (G to G)
Surface Treatment (Haze)
Haze 28%
Life time
50,000 hours (Regular)
Operation Hours (Hours/Day)
24/7
Portait / Landscape
Yes/Yes
Transparency
Not available
QWP (Quarter Wave Plate)
Not available

CONNECTIVITY

HDMI In
Yes (3 for each unit)
HDMI In (HDCP Ver.)
2.2/1.4
DP In
Yes (HDCP 2.2/1.3)
DVI-D In
Yes (HDCP 1.4)
RGB In
No
Audio In
Yes
RS232C In
Yes
RJ45(LAN) In
Yes (1 for each unit)
IR In
Yes
USB In
USB 2.0 Type A (1 per unit)
HDMI Out
Yes
DP Out
No
Audio Out
Yes
Touch USB
No
External Speaker Out
No
RS232C Out
Yes
RJ45(LAN) Out
No
IR Out
No
Daisy Chain
Input: HDMI, DP / Output: HDMI

MECHANICAL SPECIFICATION

Bezel Color
Black
Bezel Width
Even bezel : 14.9mm
Weight (Head)
41.5Kg
Weight (Head+Stand)
Not available
Packed Weight
51.2Kg
Monitor Dimensions (W x H x D)
1682.4 x 960.3 x 57.9mm (without Handle and LG Logo)
Monitor Dimension with Stand (W x H x D)
Not available
Carton Dimensions (W x H x D)
1816 x 1123 x 228mm
Handle
600 × 400 mm
VESA Standard Mount Interface
600 × 400 mm

FEATURE - HARDWARE

Internal Memory (eMMC)
16 gigabytes
Wi-Fi/BT (Built-in)
Yes
Temperature Sensor
Yes
Auto Brightness Sensor
Yes
Pixel Sensor
No
Proximity Sensor
No
Current Sensor
No
BLU Sensor
No
Humidity Sensor
No
Acceleration(Gyro) Sensor
Yes
Power Indicator
No
Local Key Operation
Yes
FAN (Built-in)
No

FEATURE - SOFTWARE

OS Ver. (webOS)
webOS 6.0
Local Contents Scheduling
Yes
Group Manager
Yes
USB Plug & Play
Yes
Fail over
Yes
Booting Logo Image
Yes
No Signal Image
Yes
RS232C Sync
Yes
Local Network Sync
Yes
Backlight Sync
No
PIP
Yes
PBP
Yes (4 pictures side by side)
Screen Share
Yes
Video Tag
Yes (4 video signals)
Play via URL
Yes
Screen Rotation
Yes
External Input Rotation
Yes
Gapless Playback
Yes
Tile Mode Setting
Yes
Setting Data Cloning
Yes
SNMP
Yes
ISM Method
Yes
Auto Set ID
Yes
Status Mailing
Yes
Control Manager
Yes
Cisco Certification
Yes
Crestron Connected
Yes
Smart Energy Saving
Yes
PM mode
Yes
Wake on LAN
Yes
Network Ready
Yes
Beacon
Yes
HDMI-CEC
Yes
SI Server Setting
Yes
webRTC
Yes
Pro:Idiom
Yes
Brightness Compensation
No
W/B Setting by Grey scale
No
Scan Inversion
No

ENVIRONMENT CONDITIONS

Operation Temperature
0 °C to 40 °C
Operation Humidity
10 % to 80 %

POWER

Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-in power supply

POWER CONSUMPTION

Typ.
170W
Max.
230W
BTU (British Thermal Unit)
581 BTU/Hr(Typ.), 785 BTU/Hr(Max.)
Smart Energy Saving (70%)
120W
DPM
0.5W
Power off
0.5W

SOUND

Speaker (Built-in)
Yes (10 watts × 2)

CERTIFICATION

Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC
ERP / Energy Star
YES(NewErP) / YES
ePEAT(US only)
No

OPS COMPATIBILITY

OPS Type compatible
Yes (Piggyback)
OPS Power Built-in
No

SOFTWARE COMPATIBILITY

SuperSign CMS
Yes
SuperSign Control+
Yes
SuperSign WB
Yes
SuperSign Cloud
Yes
Promota
Yes (Not available in the European Union/Independent States)
Mobile CMS
Yes
Connected Care
Yes

LANGUAGE

OSD
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic

ACCESSORY

Basic
Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender
Optional
OPS Kit(KT-OPSF), LSW640A/B(Wall Mount)
