All Spec
PANEL
-
Screen Size
55"
-
Brightness (w/o Protection Glass, Typ., cd/m²)
450
CONNECTIVITY
-
Input
HDMI (2), DP, DVI-D, RGB, Audio In, USB 3.0
-
Output
DP, Audio
-
External Control
RS232C In/out, RJ45 In, IR Receiver In, Pixer Sensor In
PHYSICAL SPECIFICATION
-
Bezel Width
32.7mm (Even)
-
Monitor Dimension (W x H x D)
1,278 x 748.8 x 71.4 mm
-
Weight (Head)
28.0kg
-
Carton Dimensions (W x H x D)
1,410 x 880 x 207 mm
-
Packed Weight
33kg
-
VESA™ Standard Mount Interface
300 x 300 mm
ENVIRONMENT CONDITIONS
-
Operation Temperature
0°C to 40°C
-
Operation Humidity
10 % to 80 %
POWER
-
Power Type
Built-In Power
-
Power Supply
100-240V~, 50/60Hz
POWER CONSUMPTION
-
Typ. / Max.
100W/120W
-
Smart Energy Saving
70W
SOFTWARE COMPATIBILITY
-
Content Management Software
SuperSign CMS
-
Control and Monitoring Software
SuperSign Control+
*Software compatibility may change over time.
ACCESSORY
-
Basic
Remote Controller (2ea batteries included), Power cord, QSG, RGB cable, Regulation book, Phone to RS232C gender, Memory cover
-
Optional
Stand (ST-492T), Media Player, Wall Bracket (LSW350B), VESA Adapter (AM-B330S), OPS Kit (KT-OPSA)
TOUCH
-
Touch type
IR (Scattering)
-
Scan Time
10 ms ↓
-
Interface
USB 2.0
-
Protection Glass Thickness
2.8T (Anti-Glare)
-
Operating Systme Support
Windows 7, Windows 8, Windows 8.1, Windows 10, Android (Kernel Version 3.5 Over), Linux(Kernel Version 3.5 Over), Mac OS X (10.9 Over), Chrome (39 Over)
-
Multi touch point
Max 10 Points
-
