Model name
LAD033F
Pixel Configuration
SMD
Pixel Pitch (mm)
3.3mm
No. of Modules per Cabinet (WxH)
6 (2 x 3)
Cabinet Resolution (WxH)
192 x 270
Cabinet Dimensions (W x H x D, mm)
Main : 640 x 900 x 94 (191 w/back cover) Secondary : 640 x 900 x 94 (124 w/handle)
Weight per Cabinet (kg/unit)
Main : 25 Secondary : 15
Physical Pixel Density (pixels/㎡)
90,000
Cabinet material
Iron & Aluminum
Service access
Rear only
Weight of the screen (kg)
2,650
Power Consumption (W/Cabinet, 48nit)
90 (Main) / 52 (Secondary)
Power Consumption (W/Cabinet, 300nit)
N/A
Visual Viewing Angle (Horizontal)
160, 160
Visual Viewing Angle (Vertical)
160, 160
Contrast Ratio
≥4,000:1
Processing Depth (bit)
16bit
Video Frame Rate (Hz)
24, 25, 30, 48, 50, 60
Refresh Rate (@24Hz)
3,072
Brightness (After Calibration, nit)
48(DCI)
Color Space (Gamut)
DCI P3 Theater
Bit rate (Color Processing / color)
15 (45 / total)
Power Supply (V)
AC100-240 V ~, 50/60 Hz
Operating Temperature(℃)
0℃ to 40℃
Operating Humidity
10% to 80%
LED Lifetime (Half brightness)
100,000 Hours
Certification
DCI, CB, CE-LVD/EMC, FCC, ETL/UL, RoHS, REACH
Cinema server compatibility
Dolby IMS3-L
Interface
RJ45, HDMI (on IMS server)
Screen Resolution (WxH, Native)
4,224 x 2,160
No. of Cabinets per Screen (Resolution, WxH)
176 (22 x 8)
Screen Dimensions (W x H, mm)
14,080 x 7,200 (101 sqm)
Power Type
Built-in Power
Power Consumption (W/Screen, 48nit)
9,260
Power Consumption (W/Screen, 300nit)
N/A
