Pixel Pitch(mm)
1.25
Module Resolution (WxH)
240x90
Weight per Module (kg)
0.20
Cabinet Resolution (WxH)
480x270
Cabinet Surface Area (㎡)
0.259
Weight per Cabinet (kg/Cabinet)
6.9
Weight per Square Meter (kg/㎡)
34.1
Physical Pixel Density (pixels/㎡)
640,000
Flatness of Cabinet (mm)
±0.5
Brightness (After Calibration)
600nit (Typ.) 1,200nit (Peak)
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity
97%
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
Peak. 9,000:1
Typ. 5,000:1
Power Consumption (W/Cabinet, Max.)
107
Power Consumption (W/Cabinet, Avg.)
64
Power Consumption (W/㎡, Max.)
527
Power Consumption (BTU/Cabinet, Max.)
364
Power Consumption (BTU/Cabinet, Avg.)
218
Power Consumption (BTU/㎡, Max.)
1,798
Controller
CSAA-012X
Optional Accessary
Wall Mount Kit (WM-L1080)
Frame Kit (KT-BZ1080)
Resolution
UHD (3,840 X 2,160)
Input Signal
HDMI(3), DP(1)
Output Signal
Ethernet(5GBx8ea), SPDIF(Audio)
Control
IR(1), RS232C In(1)/Out(1), Ethernet(1), USB(1)
Built-in Wi-Fi
O
Storage
16GB
Image Enhancement
HDR 10 / HDR10 Pro, 3D Color Gamut Mapping, Low Latency, Auto Brightness Control (w/ External Brightness Sensor)
Sensors
IR/Ambient Light(External), Temperature, Current
Monitoring
LDM Defect(Dot, Line), Temperature, Power(LDM, Cabinet, PSU), Receiving Card
Power Consumption (Max)
60
Power Consumption (Typical)
50
Dimension(W x H x D)
443x63x298
Weight
4.5Kg
Carton Dimensions(W x H x D)
530x169x392
Packed Weight
6.4Kg
Working Temperature (℃)
0°C~40°C (32°F to 104°F)
Operation Humidity
10% ~ 80%
Platform
webOS 4.1
SuperSign CMS
O
Signage365Care
O
LED Assistant
O
LED Calibrator
O
Basic
AC Power Cable, Phone to RS232C Gender, HDMI Cable(1), IR/Ambient Light Sensor(External), QSG, Rack Bracket, Remote, Battery
