Alle Spezifikationen
BILDSCHRIM
-
Bildschirmgröße
-
55"
-
Bildschirmtechnologie
-
OLED
-
Auflösung
-
1,920 × 1,080 (FHD)
-
Helligkeit
-
150/400 nit (APL 100% / 25%)
-
Kontrast
-
150,000 : 1
-
Farbskala
-
BT709 120%
-
Blickwinkel (H × B)
-
178 × 178
-
Farbtiefe
-
10 bit (R), 1.07 Mrd. Farben
-
Reaktionszeit
-
1 ms (G bis G) , 8 ms (MPRT)
-
Oberflächenentspiegelung (Haze)
-
Hard Coating (2 H)
Reflectance Typ. 1.2%
-
Betriebsstunden (Std. / Tage)
-
18 / 7 (bewegter Content)
-
Hoch- / Querformat
-
Ja / Ja
ANSCHLÜSSE
-
Input
-
HDMI (HDCP 1.4), DP (HDCP 1.3), USB 2.0 Type A (2)
-
Output
-
DP, Audio
-
Externe Anschlüsse
-
RS232C In / Out (w/ IR Out), RJ45 (LAN) In / Out, IR In (External IR Receiver)
MECHANISCHEEIGENSCHAFTEN
-
Rahmenfarbe
-
Schwarz
-
Rahmenstärke
-
0.6 / 6.7 / 6.7 / 0.6 mm (O/R/L/U) (Querformat, Off Bezel)
0.6 / 6.7 / 6.7 / 0.6 mm (O/R/L/U) (Hochformat, Off Bezel)
5.0 / 7.6 / 7.6 / 10.6 mm (O/R/L/U) (Querformat, On Bezel)
5.0 / 13.2 / 7.8 / 5.0 mm (O/R/L/U) (Hochformat, On Bezel)
-
Gewicht (Gerät)
-
5.8 kg (Querformat, Gerät)
7.0 kg (Hochformat Gerät)
3.5 kg (Signage Box)
-
Abmessungen (B × H × T)
-
1,224.9 × 696.2 × 38.0 mm (Querformat, Gerät mit Anschlussklemme)
701.4 × 1,219.7 × 38.0 mm (Hochformat, Gerät mit Anschlussklemme)
1,224.9 × 696.2 × 12.4 mm (Querformat, Gerät ohne Anschlussklemme)
701.4 × 1,219.7 × 12.4 mm (Hochformat, Gerät ohne Anschlussklemme)
413 × 353 × 57.3 mm (Signage Box)
HAUPTFUNKTIONEN
-
Hauptfunktionen
-
Interner Speicher (16 GB), Temperatursensor, FAN, webOS 4.0, Embedded CMS (Local Contents Scheduling, Group Manager) USB Plug & Play, Fail Over, Sync Mode (RS-232C Sync, Local Network Sync), Video Tag (4), Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting, Setting Data Cloning, SNMP, ISM Method Auto Set ID, Status Mailing, Control Manager, Crestron Connected®1), Power (PM Mode, Wake on LAN), HDMI-CEC2), SI Server Setting, Pro:Idiom
UMGEBUNGSBEDINGUNGEN
-
Betriebstemperatur
-
0°C bis 40°C
-
Betriebsluftfeuchtigkeit
-
10% bis 80%
STROM
-
Stromversorgung
-
AC 100-240 V ~, 50/60 Hz
-
Netzteil
-
Integriert
-
Stromverbrauch-Typ. / Max.
-
309 W / 318 W
-
Stromverbrauch-BTU (British Thermal Unit)
-
1,054 BTU/Hr (Typ.), 1,085 BTU/Hr (Max.)
ZERTIFIZIERUNG
-
Sicherheit
-
IEC 60950-1 / EN 60950-1 / UL 60950-1
-
EMC
-
FCC Klasse "A" / CE / KC
-
ERP
-
Ja
SOFTWARE KOMPATIBILITÄT
-
Software Kompatibilität
-
SuperSign CMS, SuperSign Control / Control+, SuperSign WB, SuperSign Media Editor, ConnectedCare3)
ZUBEHÖR
-
Zubehör
-
Fernbedienung, Netzkabel, QSG, IR Empfänger, Regulation Book, Phone to RS232C Gender, DP Cable (2 M), LAN Kabel (2 M), RS232 Kabel (4P-4P,1.5 M), LC Kabel (VLC, 3 M), Tape (4 EA for Cabling), Schrauben (M3 × L4.5, 30 EA / M3 × L5.5, 50 EA / M3 × 3.5, 10 EA), Shield Cover Assy', Tiling Set Fixer 6 EA, Flex Bar 2 EA
Compliance-Informationen
