- Kualitas Gambar Superior
- IP53 : Waterproof and Dustproof
- Magnesium & Carbon-fiber Body
- Ketersediaan Gambar Yang Cepat
- Magnesium & Carbon-fiber Body
- Peningkatan Detail Dengan MLP
Semua Spesifikasi
ACCESSORIES
CD
Manual, Calibration SW
Cable
Power cord, Manin Cable 1m (LAN Cable, Sync cable Option)
Other
Book Manual, Outgonig Inspection sheet
WARRANTY
Warranty
36 Month
BATTERY
Type
Detachable
Nominal Capacity
30W (7.5V, 4000mAh)
Nominal Voltage
7.5V
Dimensions (WxDxH, mm)
204.6 x 110.5 x 7.8
weight (g)
229.86
Operation Time
Typ. 240 shots/6.0 hrs (Condition : Interval Time 90 sec)
Battery duration in standby status
Typ. 13 hrs
SENSOR(PANEL)UNIT
TFT Type
A-Si
Scintillator
Csi
Number of Pixels
3072 x 3072
Pixel Pitch
140㎛
TFT Dimensions (WxDxH, mm)
445 x 445 mm
TFT Active Area (mm)
430.08 × 430.08 mm
X-ray sensitive Pixel
3072 x 3072
X-ray sensitive Area (mm)
430.08 x 430.08 mm
Sensor protection plate
Carbon Fiber Plate
Input
DC24V/2.1A
Power consumption
Typ. 19.0W (No Charging),30.5W (with Charging)
Weight(kg) / Icld. Battery (Typ.)
3.4kg
Maximum Load Weight
Full (Uniform Load) : 150kgLocal (Point Load) : 100kg
Falling
40cm
Cycle Time(Ethernet / WLAN)
8sec/11 sec (Ethernet/WLAN)
Full Image (Raw Image) (Typ.)
Ethernet 3sec / WLAN 6 sec
Image-lag (Typ.)
0.023%
MTF @ 0.5lp/mm
89%
MTF @ 1lp/mm
74%
MTF @ 2lp/mm
47%
MTF @ 3lp/mm
29%
DQE @ 0.1lp/mm
72%
DQE @ 0.5lp/mm
67%
DQE @ 1lp/mm
61%
DQE @ 2lp/mm
49%
DQE @ 3lp/mm
28%
Sensitivity ( lsb/uGy ) / Programmable
Typ. 600/Yes
Expected lifetime (Gy)
100 Gy
Sensitivity degradation at the 'end of Life'
20%
Spatial Resolution (lp/mm)
3.57 lp/mm
A/D Conversion
16 bit
Data Output
16 bit
Auto Exposure Detection
Yes
X-ray generator voltage range
40 to 150kVp
Unit Interface
Connect to Control Box
Power unit interface
Connect to Control Box
WLAN
IEEE802.11a/b/g/n/ac, 2.4GHz/5GHz
Wired Communication
Yes
Detachable Wire (Easy to plug / unplug)
Yes (Magnetic)
X-ray period (ms) (=Window Time)
Standard: 500 (~4000)
Sensor
DXD Rotation & degree (0, 90, 180') to rotate imageDrop count for SVC
Shock monitoring
Yes
CONTROL BOX
Power Input
AC100 to 240V, 47-63Hz
Power Output
DC24V/2.1A
AC Power Cord
1.5m, White
Dimensions (WxDxH, mm)
125 x 255 x 109.8 mm
Weight (kg)
1.3kg
CABLES
Main Cable (DXD-Control Box), Length
7m
LAN Cable (Control Box-PC), Length
10m (When Buyer requires this cable, is shipped according to BOM)
Sync Cable (Control Box - X-ray Generator), Length
15m (When Buyer requires this cable, is shipped according to BOM)
BATTERY CHARGER
Input voltage
19V
Output voltage
8.7V
Charging Time
3 Hours
Slot Q'ty
3
Bundle battery Q'ty
2
Dimensions (WxDxH, mm)
125 x 255.5 x 90.5 mm
Weight (kg)
0.9kg
AC ADAPTER FOR BATTERY CHARGER
Dimensions (WxDxH, mm)
134 x 59.8 x 31 mm
DC Cable length
1,500mm
AC Power Cord
Yes
Input
100 ~ 240VAC
Output
19V/3.42A
ENVIRONMETAL
Storage Temperature
-20 to 60 ℃
Storage Humidity
Less than 90% RH, No condensation
Storage Pressure
50 ~ 106 kPa
Storage Attitude
Less than 12,192 m
Operating Temperature
10 to 35 ℃
Operating Humidity
Less than 80% RH, No condensation
Operating Pressure
70 ~ 106 kPa
Operating Attitude
Less than 5000 m
WATERTIGHTNESS
Watertightness
IP41
Cleaning and desinfecting products
Isopropanel 100%, Ethanol 70%, Cidex OPA, 0.9% Nacl solution
Anti-Bacteria
JIS Z 2801 0.99%
