Summary

- Active Energy Control
- Anti Bacterial Filter
- Fresh Dry
- 10 Year Warranty On Inverter Compressor
- 5 Star Energy Rating
DIMENSIONS
All Spec
COOLING CAPACITY
W
2696
Btu/h
9,200
Capacity Rate Min
2,200 Btu/h
Capacity Rate Max
11,900 Btu/h
POWER INPUT
Cooling (W)
810
EER
W/W
3.33
Btu/h.W
11.36
POWER SUPPLY
Ø / V / Hz
1 / 220~240 / 50
AIR FLOW RATE
Indoor,Max ( ㎥/min(CFM) )
11
Outdoor,Max ( ㎥/min(CFM) )
28
MOISTURE REMOVAL
l/h.
0.4
SOUND LEVEL
Indoor,H/M/L/SL ( dB(A)±3 )
36 / 30 / 24 / 18
Outdoor,Max ( dB(A)±3 )
47
STANDARD PIPE LENGTH
Length ( m )
7.5
RUNNING CURRENT
Cooling(A)
4.5
PIPING CONNECTIONS
Liquid (mm)
6.35
Gas (mm)
9.52
NET WEIGHT
Indoor Unit(kg/lbs)
8.5
Outdoor Unit (kg/lbs)
22.6
DIMENSION
Indoor Unit (WxHxD) (mm/inch)
837*302*189
Outdoor Unit (WxHxD) (mm/inch)
720*500*270
PRE-FILTER (IN FRONT GRILLE)
Anti bacteria air filter (Stallion Prefilter)
Yes (Top Filter)
FUNCTIONS
*Vane Horizontal
Normal
Temperature Control
Thermistor
Auto Clean
Yes
Natural Wind
Yes
Fan Speed(SH/H/MH/M/ML/L/SL)
7
Airflow Direction Control(up & Down)
Auto
Airflow Direction Control(left & right)
Manual
Setting Temperature Range-Cooling(°C)
16-30
Temperature Increment (°C)
1
Auto Operation (Micom Control)
Yes
Self Diagnosis
Yes
Timer
24hr On/Off
Sleep Operation
Yes
Restart Delay(minute)
3
Display Light (On/Off)
Yes
Jet Cool
Yes
SPECIAL FUNCTION
Fresh Dry
Yes
Indirect Air
Yes
Active Energy Control
Yes
FAN(INDOOR)
Type
Cross Flow Fan
FAN(OUTDOOR)
Type
Fan,Propeller
SPECIAL FILTER
Micro Dust Filter (single)
Yes
