Concealed Duct, Mid/High Static Duct, 48kBTU

Concealed Duct, Mid/High Static Duct, 48kBTU

Concealed Duct, Mid/High Static Duct, 48kBTU

ARNU48GM3A4
Front view of Concealed Duct, Mid/High Static Duct, 48kBTU ARNU48GM3A4
Front view of Concealed Duct, Mid/High Static Duct, 48kBTU ARNU48GM3A4

Key Features

  • External Static Pressure (ESP) Control
  • Wi-Fi Control with ThinQ
  • Static Pressure 11- Step Control
  • Clean Air (Safe Plus Insulation)
More

External Static Pressure Control

The user has easy access to air volume selection via the remote control by using the ESP control function. The BLDC motor can control the fan speed and air volume.

No additional accessories are needed to control air flow.

Wi-Fi Control with ThinQ

Get access to the unit anytime, anywhere with Android & iOS smartphones.

Static Pressure 11- Step Control

Depending on the installation environment, LG’s ceiling conceals duct controls of static pressure with 11 steps to provide maximized comfort to any environment.

Clean Air (Safe Plus Insulation)

Safe Plus Insulation is an antimicrobial treatment that is applied to the LG MULTI V Indoor unit.

Internal insulation components create resistance against bacterial growth and provide cleaner and fresher airflow for the user.

Print

All Spec

POWER SUPPLY

  • #1

    50 Hz(Гц) 220-240 V(B)~

  • #2

    60 Hz(Гц) 220 V(B)~

CONNECTING PIPE

  • Liquid (mm(inch))

    Φ9.52 (3/8)

  • Gas (mm(inch))

    Φ15.88 (5/8)

COOLING CAPACITY

  • Nominal (kW)

    14.10

DIMENSIONS

  • Net(W x H x D) (mm)

    1250 x 360 x 700

HEATING CAPACITY

  • Nominal (kW)

    15.9

INDOOR FAN

  • Air Flow Rate(Cooling,(SH)/H/M/L) (m³/min)

    -/40/34/28

  • External Static Pressure(Factory Set) (Pa)

    59

PRODUCT

  • Type

    Concealed Duct

SOUND POWER LEVEL (INDOOR UNIT)

  • Cooling((SH)/H/M/L) (dB(A))

    -/63/60/59

  • Heating((SH)/H/M/L) (dB(A))

    -/63/60/59

SOUND PRESSURE LEVEL (INDOOR UNIT)

  • Cooling((SH)/H/M/L) (dB(A))

    -/41/38/37

  • Heating((SH)/H/M/L) (dB(A))

    -/41/38/37

WEIGHT

  • Net (kg)

    42.2

To access more technical documentation and resources, please visit the LG B2B partner portal.
