Alle Spezifikationen
BETRIEBSSTROM
-
#1
-
50 Hz 380-415 V 3N~
-
#2
-
60 Hz 380 V 3N~
KÜHLLEISTUNG
-
Nennleistung (kW)
-
33.6
HEIZLEISTUNG
-
Nennleistung (kW)
-
37.8
LEISTUNGSAUFNAHME(KÜHLEN)
-
Nennleistung (kW)
-
5.14
LEISTUNGSAUFNAHME(HEIZEN)
-
Nennleistung (kW)
-
5.56
KOMPRESSOR
-
Typ
-
Hermetically Sealed Scroll
-
Modell x Nr.
-
JQC068MAA x 1
-
Hubvolumen (cm³/rev)
-
62.1
-
Umdrehungszahl (rev./min)
-
3600
-
Motorleistung (W x No.)
-
5300 x 1
-
Startverfahren
-
Direct On Line
-
Öltyp
-
FW68D(PVE)
-
Ölfüllmenge (cc x No.)
-
1,200 x 1
WÄRMETAUSCHER
-
Typ
-
Stainless Steel Plate
-
Maximaler Druckwiderstand (kg/cm²)
-
45
NENNDURCHFLUSS(L/MIN)
-
Nenndurchfluss (l/min)
-
115
DRUCKVERLUST(KPA)
-
Druckverlust (kPa)
-
22.1
ABMESSUNGEN
-
Netto(B x H x T) (mm)
-
772 x 1120 x 547
GEWICHT
-
Netto (kg)
-
149 x 1
ÄUSSERES
-
Farbe
-
Morning Gray / Dawn Gray
-
RAL (klassisch)
-
RAL 7038 / RAL 7037
KÄLTEMITTEL
-
Typ
-
R410A
-
Werksfüllung (kg)
-
3.5
-
Kontrollart
-
Electronic expansion valve
ROHRLEITUNGSANSCHLÜSSE
-
Flüssig (mm(inch))
-
Φ12.7 (1/2)
-
Gas (mm(inch))
-
Φ28.58 (1-1/8)
-
Niederdruckgas (Wärmerückgewinnung) (mm(inch))
-
Φ28.58 (1-1/8)
-
Hochdruckgas (Wärmerückgewinnung) (mm(inch))
-
Φ19.05 (3/4)
WASSERANSCHLUSSLEITUNGEN
-
Eintritt (mm)
-
PT 40 (Internal Thread)
-
Austritt (mm)
-
PT 40 (Internal Thread)
SCHALLDRUCKPEGEL(AUSSENEINHEIT)
-
Kühlen / Heizen (dB(A))
-
48 / 51
SCHALLLEISTUNGSPEGEL(AUSSENEINHEIT)
-
Kühlen / Heizen (dB(A))
-
60 / 63
VERBINDUNGSKABEL
-
Datenleitung(VCTF-SB) (mm² × cores)
-
1.0 ~ 1.5 × 2C
EINSATZGRENZEN KONTINUIERLICHER BETRIEB(INNENTEMP.)
-
Kühlen (°C(WB))
-
15 ~ 40
-
Heizen (°C(DB))
-
15 ~ 40
EINSATZGRENZEN(INNENTEMP.)
-
Kühlen (°C(WB))
-
10 ~ 45
-
Heizen (°C(DB))
-
-5 ~ 45
