Bist du dir sicher, dass du die Prämie entfernen möchtest?

- Externe statische Pressung (ESP Control)
- Wi-Fi-Steuerung mit ThinQ
- Statische Pressung 11-Stufen-Steuerung
- Flexible Installation
Alle Spezifikationen
BETRIEBSSTROM
#1
50 Hz 220-240 V~
#2
60 Hz 220 V~
KÜHLLEISTUNG
Nominal (kW)
6.3
HEIZLEISTUNG
Nominal (kW)
7.1
ABMESSUNGEN
netto(B x H x T) (mm)
1,100 x 190 x 460
GEWICHT
Netto (kg)
22
ROHRLEITUNGSANSCHLÜSSE
flüssig (mm(inch))
Φ9.52 (3/8)
Gas (mm(inch))
Φ15.88 (5/8)
LÜFTER INNEN
Luftdurchsatz (Kühlen, (SH)/H/M/L) (m³/min)
- / 17.5 / 14.0 / 12.0
Äußerer statischer Druck (Werkseinstellung) (Pa)
10
ABFLUSSROHR(MIT ABFLUSSPUMPE)
AE / IE (mm(inch))
-/25.4(1)
SCHALLDRUCKPEGEL(INNENEINHEIT)
Kühlen((SH)/H/M/L) (dB(A))
- / 35.0 / 30.0 / 29.0
Heizen((SH)/H/M/L) (dB(A))
- / 35.0 / 30.0 / 29.0
SCHALLLEISTUNGSPEGEL(INNENEINHEIT)
Kühlen((SH)/H/M/L) (dB(A))
- / 42.5 / 38.3 / 36.0
Heizen((SH)/H/M/L) (dB(A))
- / 42.5 / 38.3 / 36.0
PRODUKT
Typ
Kanalklimagerät
Compliance-Informationen
