Air Flow Rate - Cooling, Max/H/M/L
20 / 15 / 12.5 / 10.6 m³/min
Sound Pressure Level - Cooling, Max/H/M/L/SL
- / 47 / 41 / 37 / 32 dB(A)
Dimensions (W × H × D) - Net
998 × 345 × 210 mm
Dimensions (W × H × D) - Shipping
1068 × 425 × 279 mm
Weight - Net
11.6kg
Weight - Shipping
13.4kg
Exterior Color Code
Munsell 7.5BG 10/2 (RAL 9016)
Air Flow Rate - Max
49.0 m³/min
Fan Motor Speed - Cooling, Min ~ Max
190 ~ 940 rpm
Sound Pressure Level - Cooling, Rated
55 dB(A)
Dimensions (W × H × D) - Net
870 × 650 × 330 mm
Dimensions (W × H × D) - Shipping
1040 × 710 × 455 mm
Weight - Net
42.5kg
Weight - Shipping
45.9kg
Max. Fuse Size
20A
Exterior Color Code
Munsell 9.54Y 8.34/1.31 (RAL 9001)
Operation Range - Cooling
18 ~ 48 °C DB
Cooling (Min ~ Rated ~ Max)
315 ~ 1,850 ~ 2,600 W
EER
3.41 W/W11.62 (Btu/h)/W12.26 (kJ/h)/W
Evaporator - Material, Tube / Fin
Cu/Al
Evaporator - (ø x Row x Column x FPI x L) x Qty.
(ø7 x 2 x 16 x 20 x 744) x 1
Evaporator - Corrosion Protection
PCM
Evaporator - Fin Type
Slit
Condenser - Material, Tube / Fin
Cu/Al
Condenser - (ø x Row x Column x FPI x L) x Qty.
(ø7 x 2 x 28 x 18 x 940) x 1
Condenser - Corrosion Protection
Gold
Condenser - Fin Type
Louver
Type
Twin Rotary
Model
DAT156MAD
Motor Type
BLDC
Oil Type / Maker
PVE (FW68D) / IDEMITSU
Oil Charge
400cc
Manufacturer / Country of Origin
LG Electronics / China
Type
R32
Pre Charge
1150g
Additional Charge
20g/m
Control
Electronic Expansion Valve
Global Warning Potential
675
t-CO₂ eq
0.776
Cooling (Min ~ Rated ~ Max)
1.60 ~ 8.50 ~ 12.00 A
Power Supply
1, 230, 60 (Ø, V, Hz)
Available Voltage Range
187 ~ 276 V
Power Factor - Cooling
97.2%
Moisture Removal
2.80 l/h
Cooling (Min ~ Rated ~ Max)
1.81 ~ 6.30 ~ 6.98 kW6,161 ~ 21,500 ~ 23,800 Btu/h6,500 ~ 22,683 ~ 25,109 Btu/h
Capacity
2.5HP
Circuit Breaker
30A
Power Supply Cable
3 x 1.5 No. x mm²
Power Supply to Unit
Indoor
Power and Communication Cable
4 x 1.5 No. x mm²
Size - Liquid
ø 6.35 mm
Size - Gas
ø 15.88 mm
Connections Method - Indoor/Outdoor
Flared/Flared
Drain Hose Size - O.D, I.D
21.5, 16.0 mm
Piping Length - Min/Standard/Max
3/7.5/30 m
Piping Length - No Change
12.5 m
Max. Elevation Difference
20m
Piping Connection Heat Insulation
Both liquid and gas pipes
Type
Cross Flow Fan
Motor Output
30W
Type
Propeller Fan
Motor Type
BLDC
Motor Output
85W
Motor Insulation
Class E
Motor Enclosure / Ingress Protection
TEAO/IPX4
