Capacity - Cooling (Rated)
13.51kW
46,100Btu/h
Power Input - Cooling (Rated)
3.88kW
Running Current - Cooling (Rated)
17.0A
Power Supply (V , Ć , Hz)
230, 1, 60
Wiring Connections - Power Supply Cable (included Earth)
3C No.x 6.0 mmĀ²(10AWG)
Dimensions - (WxHxD)
950 x 1,380 x 330 mm
37-13/32 x 54-11/32 x 13 inch
Net Weight
89.0kg (196.2lbs)
Compressor - Type
Twin Rotary
Compressor - Model
GPT442MAB Model x 1 No.
Compressor - Motor type
BLDC
Compressor - Motor Output
4,000W (at 60Hz) x 1 No.
Refrigerant - Type
R410A
Refrigerant - Precharged Amount
3,400g (119.9oz)
Refrigerant - Chargeless - Pipe Length
5m (16.4ft)
Refrigerant - Additional Charging Volume
40g/m (0.43oz/ft)
Refrigerant - Control
Electronic Expansion Valve
Refrigerant Oil - Type
FVC68D (PVE)
Refrigerant Oil - Charged volume
1,300cc x 1 No.
Heat Exchanger - (Row x Column x FPI) x No.
(2 x 32 x 16) x 2
Fan - Type
Propeller
Fan - Air Flow Rate
120 x 2m3/min
Fan Motor - Type
BLDC
Fan Motor - Output
124.2W x 2 No.
SoundPressure Level - Cooling (Rated)
62dB (A)
Piping Connections - Liquid (Outer Dia.)
Ć9.52mm (3/8inch)
Piping Connections - Gas (Outer Dia.)
Ć19.05mm (3/4inch)
Piping Length (Max.)
30m (98.4ft)
Maximum Height Difference - Outdoor Unit ~ Indoor Unit (Max.)
20m (65.6ft)
Opefatio Range (Outdoor Teriperatvre) - Cooling (Min. - Max.)
0Ā°C (32.0Ā°F) - 54DB (129.2DB)
