Pixel Configuration
1R, 1G, 1B (Chip on Board)
Pixel Pitch (mm)
0.93
Module Resolution (W x H)
160 × 180
Module Dimensions (W x H, mm)
150 × 168.8
Weight per Module (g)
150
No. of Modules per Cabinet (W × H)
8 (4 × 2)
Cabinet Resolution (W × H)
640 × 360
Cabinet Dimensions (W × H × D, mm)
600 × 337.5 × 44.9
Cabinet Surface Area (m²)
0.203
Weight per Cabinet (kg/cabinet)
7.0
Weight per Square Meter (kg/m²)
34.6
Physical Pixel Density (pixels/m²)
1,137,778
Flatness of Cabinet (mm)
±0.5
Cabinet Material
Die-casting Aluminum
Service Access
Front and Rear (Module : Front Only)
Min. Brightness (After Calibration)
1,200 nit (Peak.) / 600 nit (Max.)
Color Temperature
7,300 K / 3,200~9,300 K (Adjustable by LED Assistant on PC)
Visual Viewing Angle (H×V)
160° × 160°
Brightness Uniformity
≥ 95%
Color Uniformity
±0.02Cx, Cy
Contrast Ratio (10 lux)
150,000 : 1
Processing Depth (bit)
20
HDR Compatibility
HDR10, HDR10 Pro*
* HDR10 Pro is LG's own HDR solution to process HDR signal by using enhanced dynamic tone mapping.
Driver-IC Type
Common Cathode
Power Consumption (W/cabinet, Max.)
125
Power Consumption (W/cabinet, Avg.)
85
Power Consumption (W/m², Max.)
617
Heat Dissipation (BTU/h/Cabinet, Max.)
426
Heat Dissipation (BTU/h/Cabinet, Avg.)
290
Heat Dissipation (BTU/h/m², Max.)
2,104
Power Supply (V)
100 to 240
Frame Rate (Hz)
50/60
Refresh Rate (Hz)
3,840
Controller
CSAB-009X
Lifetime (Hours to Half Brightness)
100,000
Operating Temperature
0°C to +40°C
Operating Humidity
10-80% RH
IP Rating (Front / Rear)
IP50 / IP20
Certification
Safety 60950-1, EMC Class A, BS476 Part 7 Class 1
Environment
RoHS
Optional Accessory
Wall Mount Kit, Frame Kit
