Wired Digital X-ray Detector
Contact Us

Wired Digital X-ray Detector

Contact Us

Wired Digital X-ray Detector

17HK700G-W
LG Wired Digital X-ray Detector, 17HK700G-W
LG Wired Digital X-ray Detector, 17HK700G-W

Key Features

  • Light yet durable carbon-fiber housing
  • Raw image in 2 sec. (wired)
  • IP53: Water and Dust Resistant
  • Highly sensitive Csl AED detector (16 bit A/D conversion)
More
Watch the video
Ensure Diagnostic Accuracy

Superior Image Quality

LG DXD guarantees high resolution and clear image quality without image distortion through 16bit image processing. Plus, it also supports ideal pixel pitches of 140㎛ for high resolution images.
Superior Image Quality
Superior Image Quality
Superior Image Quality
Superior Image Quality
Superior Image Quality
Superior Image Quality
Superior Image Quality
Superior Image Quality
Superior Image Quality
Superior Image Quality
Light yet Durable

Light yet Durable

IP53: Water and Dust Resistant

IP53: Water and Dust Resistant

IP53 resistance rating* ensures that LG DXD will be partially protected against dust that may harm the equipment and moisture spray up to 60 degrees from vertical.

*Ingress protection code IEC standard 60529.

Magnesium & Carbon-fiber Body

Magnesium & Carbon-fiber Body

With a super strong body that combines carbon-fiber with magnesium, LG DXD is not only lightweight, but also exceptionally strong.

*Maximum load weight: uniform load 300kg (661lb), point load 100kg (220lb)

Rapid Image Availability
Improve Work Efficiency

Rapid Image Availability

LG DXD increases productivity with a fast-processing. It takes only 2 seconds to get a raw image.
Print

All Spec

BATTERY

  • Hot swap

    NO

CONTROL BOX

  • AC Power Cord

    1.5m (White)

SENSOR(PANEL) UNIT

  • AP mode

    NO

  • Auto Exposure Detection

    YES

  • A/D Conversion

    16bit

  • Data Output

    16bit

  • Detachable Wire(Easy to plug / unplug)

    Screw Fix

  • Falling (IEC60601-1 Test Condition)

    1m

  • Image storage on DXD

    200

  • Pixel Pitch

    140㎛

  • Power unit interface

    Connect to Control Box

  • Scintillator

    CsI

  • Sensor protection plate

    Carbon Fiber Plate

  • Shock monitoring

    YES

  • TFT Type

    aSi

  • Unit Interface

    Connect to Control Box

  • Wired Communication

    YES

To access more technical documentation and downloads, please visit the LG B2B Partner Portal.
