Case 1
400, 3, 50/60
Limit Range of Voltage(Case 1) (V)
342 ~ 456V
Nominal Capacity (RT)
20
Net(Min ~ Rated ~ Max) (kW)
30.50~70.00~90.30
Net(Min ~ Rated ~ Max) (kcal/h)
26,210~60,480~77,610
Net(Min ~ Rated ~ Max) (Btu/h)
104,000~240,000~308,000
Gross(Min ~ Rated ~ Max) (kW)
32.50~72.30~92.30
Gross(Min ~ Rated ~ Max) (kcal/h)
27,950~62,220~79,350
Gross(Min ~ Rated ~ Max) (Btu/h)
110,900~246,900~314,900
Cooling(Min ~ Rated ~ Max) (kW)
11.90~21.30~32.10
EER (Btu / Wh)
11.3
IEER (Btu / Wh)
19
Type
Propeller Fan
Diameter (mm(inch))
680(26-25/32)
Air Flow Rate(Nominal) (㎥/min x No.)
105 x 4
Discharge direction
Top
Drive
BLDC Inverter
Output (W x No.)
900 x 4
Type
Plug Fan
Diameter (mm(inch))
630(25)
Air Flow Rate(Nominal) (㎥/min)
227
Drive
BLDC Inverter
Output (HP x No.)
10 x 1
No. (EA)
2
Size(W x H x D) (inch)
75 x 20 x 0.28
No. (EA)
6
Size(W x H x D) (inch)
25 x 20 x 2
Type
HSS DC SCROLL
Motor Output (W x No.)
5,500 x 1
Oil Type
FW68D(PVE)
Oil Charging amount (cc x No.)
1,500 x 1
Type
HSS DC SCROLL
Motor Output (W x No.)
5,500 x 1
Oil Type
FW68D(PVE)
Oil Charging amount (cc x No.)
1,500 x 1
Rows x Columns x FPI
(3×52×16)×2
Fin Type
Wide Louver Plus
Tube size(Outer Dia.) (mm(inch))
7(9/32)
Face Area (㎡)
4.5
Rows x Columns x FPI
(4×44×18)×2
Fin Type
LG Louver
Tube size(Outer Dia.) (mm(inch))
9.52(3/8)
Face Area (㎡)
2.01
Net(W x H x D) (mm)
2,230 x 1,242 x 3,520
Net (kg)
940
Type
R410A
Precharged Amount(A-Circuit) (kg)
9
Precharged Amount(B-Circuit) (kg)
9
Control Type
EEV
Dehumidification Rate (ℓ/h)
24.1
Drain Connection Size (inch)
Male NPT 1"
Cooling / Heating (dB(A))
77.0 / -
Minimium Circuit Amperes (MCA) (A)
88
Maximum Fuse Amperes (MFA) (A)
100
Comp_Rated Load Amperes (A)
58.8
Outdoor Fan Motor_Full Load Amperes (FLA) (A)
8
Indoor Fan Motor_Full Load Amperes (FLA) (A)
6.5
