Case 1
380-400-415, 3, 50/60
Limit Range of Voltage(Case 1) (V)
342 ~ 456 V
Nominal Capacity (RT)
10
Net(Min ~ Rated ~ Max) (kW)
18.20~34.30~38.10
Net(Min ~ Rated ~ Max) (kcal/h)
15,630~29,490~32,770
Net(Min ~ Rated ~ Max) (Btu/h)
62,000~117,000~130,000
Gross(Min ~ Rated ~ Max) (kW)
19.10~35.20~39.00
Gross(Min ~ Rated ~ Max) (kcal/h)
16,420~30,240~33,560
Gross(Min ~ Rated ~ Max) (Btu/h)
65,000~120,000~133,000
Net(Min ~ Rated ~ Max) (kW)
18.20~34.30~38.10
Net(Min ~ Rated ~ Max) (kcal/h)
15,630 ~ 29,490 ~ 32,770
Net(Min ~ Rated ~ Max) (Btu/h)
62,000 ~ 117,000 ~ 130,000
Cooling(Min ~ Rated ~ Max) (kW)
2.80~10.08~15.50
Heating(Min ~ Rated ~ Max) (kW)
2.80~9.80~15.50
EER (Btu / Wh)
11.6
IEER (Btu / Wh)
19
COP (W/W)
3.5
Type
Propeller Fan
Diameter (mm(inch))
680(26-25/32)
Air Flow Rate(Nominal) (㎥/min x No.)
105 x 1
Discharge direction
Top
Drive
BLDC Inverter
Output (W x No.)
1,500 x 1
Type
Plug Fan
Diameter (mm(inch))
560 (22)
Air Flow Rate(Nominal) (㎥/min)
113
Drive
BLDC Inverter
Output (HP x No.)
10 x 1
No. (EA)
1
Size(W x H x D) (inch)
40 X 40 X 0.28
No. (EA)
4
Size(W x H x D) (inch)
20 X 20 X 2
Type
HSS DC SCROLL
Motor Output (W x No.)
5,500 x 1
Oil Type
FW68D(PVE)
Oil Charging amount (cc x No.)
1,500 x 1
Rows x Columns x FPI
(3 x 52 x 14) x 1
Fin Type
Wide Louver Plus
Tube size(Outer Dia.) (mm(inch))
7(9/32)
Face Area (㎡)
2.4
Rows x Columns x FPI
(4 × 22 × 16) × 2
Fin Type
LG Louver
Tube size(Outer Dia.) (mm(inch))
9.52(3/8)
Face Area (㎡)
1.01
Net(W x H x D) (mm)
1,130 x 1,242 x 2,250
Net (kg)
440
Type
R410A
Precharged Amount(A-Circuit) (kg)
9
Control Type
EEV
Dehumidification Rate (ℓ/h)
12.1
Drain Connection Size (inch)
Male NPT 3/4"
Cooling / Heating (dB(A))
80.0 / 80.0
Minimium Circuit Amperes (MCA) (A)
43
Maximum Fuse Amperes (MFA) (A)
50
Comp_Rated Load Amperes (A)
28.8
Outdoor Fan Motor_Full Load Amperes (FLA) (A)
3
Indoor Fan Motor_Full Load Amperes (FLA) (A)
4
