- Brightness : 500 nit (Typ.)
- Resolution : ULTRA HD (3,840 x 2,160)
- Bezel : 17 mm (Even bezel)
- Built-in Speaker (10 W + 10 W)
- Interface : HDMI(3) / DP / DVI-D / USB 2.0 / RS232C / RJ45 / Audio / IR & Light Sensor
All specs
CERTIFICATION
Safety
CB / NRTL
EMC
FCC Class "A" / CE / KC
ERP / Energy Star
Yes(NewErP) / No
LANGUAGE
OSD
English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkiye, Arabic, Polski
MECHANICAL SPECIFICATION
Bezel Width
Even bezel : 17mm
Bezel Color
Black
Weight (Head)
78Kg
Packed Weight
105Kg
Monitor Dimensions (W x H x D)
2198 x 1253 x 79.5mm
Carton Dimensions (W x H x D)
2455 x 1458 x 288mm
Handle
Yes
VESA Standard Mount Interface
800 x 400
ENVIRONMENT CONDITIONS
Operation Humidity
10 % to 80 %
Operation Temperature
0 °C to 40 °C
POWER
Power Type
Built-In Power
Power Supply
AC 100-240V~, 50/60Hz
SOFTWARE COMPATIBILITY
Connected Care
Yes
SuperSign CMS
Yes
SuperSign Control+
Yes
SuperSign WB
Yes
SuperSign Cloud
Yes
Mobile CMS
Yes
PANEL
Contrast Ratio
1,200:1
Screen Size (Inch)
98"
Panel Technology
ADS
Back Light Type
Direct
Aspect Ratio
16:9
Native Resolution
3840 x 2160 (UHD)
Refresh Rate
60Hz
Dynamic CR
200,000:1
Color Gamut
DCI-P3 88%↑
Viewing Angle (H x V)
178 X 178
Response Time
8ms (G to G)
Surface Treatment (Haze)
25%
Life time
30,000Hrs (Min)
Operation Hours (Hours/Day)
16/7
FEATURE - HARDWARE
Local Key Operation
Yes
Temperature Sensor
Yes
Auto Brightness Sensor
Yes
Acceleration(Gyro) Sensor
Yes
Power Indicator
Yes
CONNECTIVITY
Daisy Chain
Yes(Input HDMI, DP, DVI / Output HDMI)
HDMI In
Yes(3), HDMI1/HDMI2 : HDCP 2.2/1.4 HDMI3 : HDCP 1.4
DP In
Yes(1), HDCP2.2/1.3
DVI-D In
Yes(1), HDCP1.4
Audio In
Yes(1)
RS232C In
Yes(1), 4pin Phone-jack
RJ45(LAN) In
Yes(1)
IR In
Yes(1)
USB In
USB2.0 Type A(1)
HDMI Out
Yes(1)
Audio Out
Yes(1)
RS232C Out
Yes(1), 4pin Phone-jack
FEATURE - SOFTWARE
Pro:Idiom
Yes
Local Contents Scheduling
Yes
Group Manager
Yes
USB Plug & Play
Yes
Fail over
Yes
Booting Logo Image
Yes
No Signal Image
Yes
RS232C Sync
Yes
Local Network Sync
Yes
PIP
Yes
PBP
Yes (4)
Screen Share
Yes
Video Tag
Yes (4)
Play via URL
Yes
Screen Rotation
Yes
External Input Rotation
Yes
Gapless Playback
Yes
Tile Mode Setting
Yes (Max. 15x15)
Setting Data Cloning
Yes
SNMP
Yes
ISM Method
Yes
Auto Set ID
Yes
Status Mailing
Yes
Control Manager
Yes
Smart Energy Saving
Yes
PM mode
Yes
Wake on LAN
Yes
Network Ready
Yes
Beacon
Yes
HDMI-CEC
Yes
SI Server Setting
Yes
webRTC
Yes
POWER CONSUMPTION
BTU (British Thermal Unit)
1467 BTU/Hr(Typ.), 1911 BTU/Hr(Max)
Smart Energy Saving (70%)
301W
DPM
0.5W
Power off
0.5W
Max.
560W
Typ.
430W
ACCESSORY
Basic
Remote Controller(include battery 2ea), Power Cord, QSG, IR/Light sensor receiver, Regulation Book, Phone to RS233C Gender
