All specs

ACCESSORY

  • Basic

    Remote Controller, Power Cord, QSG, HDMI Cable, Regulation Book, Phone to RS232C Gender

CERTIFICATION

  • EMC

    CE Class A

  • Safety

    CB

CONNECTIVITY

  • External Control

    RS232C in/out, RJ45 in, IR in

  • Input

    HDMI (2), DP, USB 2.0 (2)

  • Output

    HDMI, DP(Daisy chain only)

ENVIRONMENT CONDITIONS

  • Operation Humidity

    10 % to 80 %

  • Operation Temperature

    0°C to 40°C

KEY FEATURE(HARDWARE)

  • Key Feature (Hardware)

    Internal Memory 8GB (System 4GB, Available 4GB), Wi-Fi Built-in (ac combo), Thermal Sensor, Power Indicator, Local Key Operation

KEY FEATURE(SOFTWARE)

  • Beacon

    Yes

  • Content Rotation

    Yes

  • Content Sync.

    RS-232C, Local Network

  • Control Manager

    Yes

  • Daylight Saving Time

    Yes

  • Embedded CMS

    USB Auto Playback, Local Contents Scheduling, Group Manager

  • Fail over

    Yes

  • Firmware Update by Network

    Yes

  • Gapless Playback

    Yes

  • HDMI-CEC

    Yes *Compatibility may differ by equipment.

  • Image Customization

    No Signal

  • ISM Mode(Image Sticking Minimization)

    Yes

  • Lock mode

    Yes (Home Dashboard, USB, OSD, IR Operation, Local Key, WiFi, Screen Share)

  • Multi-screen

    PIP/PBP(4)

  • OSD Rotation

    Yes

  • Play via URL

    Yes

  • Power Mgmt.

    DPM, On/Off Schedule, Holiday Schedule, Power on Status, Smart Energy Saving, Wake on LAN, Power on Delay

  • Screen Share

    Yes

  • Setting Data Cloning

    Yes (Network, USB)

  • SI Server Setting

    Yes

  • SNMP(ver.2)

    Yes

  • Status Mailing

    Yes

  • Tile Mode Setting

    Yes (Max. 15x15)

  • Video Tag

    Yes (2)

  • webOS ver.

    webOS 4.0

  • webRTC

    Yes

MECHANICAL SPECIFICATION

  • Carton Dimensions (W × H × D)

    314 x 124 x 359 mm

  • Packed Weight

    2.26 kg

  • Player Dimension (W x H x D)

    258 × 36.5 × 186 mm

  • Weight

    1.4 kg

POWER

  • Power Supply

    100-240V~, 50/60Hz

  • Power Type

    Built-In Power

POWER CONSUMPTION

  • Typ./Max

    16W/22W

SOFTWARE COMPATIBILITY

  • Content Management Software

    SuperSign CMS

  • Control and Monitoring Software

    SuperSign Control/Control+
