Interactive Digital Board

Interactive Digital Board

All specs

PANEL

  • Screen Size

    86"

  • Brightness(Module, Typ., cd/m²)

    410

CONNECTIVITY

  • Input

    HDMI (3), DP, DVI-D, RGB, Audio, USB 3.0, USB 2.0, OPS USB 2.0

  • Output

    Touch USB 2.0 (2)

PHYSICAL SPECIFICATION

  • Bezel Width

    50.7 mm (T/L/R), 62.2 mm (B)

  • Monitor Dimension (W x H x D)

    2,026.9 x 1,180.3 x 79.5 mm (w/o Handle)

  • Weight (Head)

    85.8 kg

  • Carton Dimensions (W x H x D)

    2,190 × 1,470 × 371 mm

  • Packed Weight

    114.6 kg

  • VESA™ Standard Mount Interface

    600 x 400 mm

ENVIRONMENT CONDITIONS

  • Operation Temperature

    0°C to 40°C

  • Operation Humidity

    10% to 80%

SOFTWARE COMPATIBILITY

  • Content Management Software

    SuperSign Premium

  • Control and Monitoring Software

    SuperSign Link

ACCESSORY

  • Basic

    Remote Controller (include battery 2ea), Power Cord, QSG, HDMI (3M), Regulation Book, Phone to RS232C Gender, Touch Pen (2ea), Eyebolt (2ea)

  • Optional

    OPS Kit (KT-OPSA)

TOUCH

  • Touch type

    InGlass™

  • Available Object Size for Touch

    more than Ø 3 mm

  • Accuracy

    2 mm

  • Interface

    USB 2.0

  • Protection Glass Thickness

    4T (Anti-Glare)

  • Multi Touch Point

    Max 20 Point
