Ultra Stretch Signage

Ultra Stretch Signage

Ultra Stretch Signage

86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B
LG Ultra Stretch Signage, 86BH5F-B

Key Features

  • Brightness(Typ.) : 500 cd/m²
  • Aspect Ratio: 58:9
  • Bezel: 4.4 mm(L/R), 5.9 mm(T/B)
  • Depth: 81.7mm
  • Interface: HDMI (3), DP, USB(2), Audio, DVI-D, RS232C, RJ45, IR
More
Print

All specs

ACCESSORY

  • Basic

    Remote Controller, Power Cord, DP Cable, RS-232C Cable, IR/Light Sensor Receiver, Manual

  • Optional

    OPS Kit (KT-OPSF)

CONNECTIVITY

  • Input

    HDMI (3), DP, DVI-D, Audio, USB 2.0 (2)

  • Output

    DP, Audio

  • External Control

    RS232C In/out, RJ45 (LAN) In/out, IR In

ENVIRONMENT CONDITIONS

  • Operation Temperature Range

    0 °C to 40 °C

  • Operation Humidity Range

    10 % to 80 %

MECHANICAL SPECIFICATION

  • Bezel Color

    Black

  • Bezel Width

    4.4 mm (L/R), 5.9 mm (T/B)

  • Monitor Dimension (W × H × D)

    2,158.3 x 348.5 × 81.7 mm

  • Weight (Head)

    20.5 kg

  • Carton Dimensions (W × H × D)

    2,290 x 599 x 228 mm

  • Packed Weight

    38.2 kg

  • Handle

    Yes

  • VESA™ Standard Mount Interface

    600 x 200 mm

MEDIA PLAYER COMPATIBILITY

  • OPS type compatible

    Yes (Piggyback)

PANEL

  • Screen Size

    86"

  • Panel Technology

    IPS

  • Aspect Ratio

    58:9

  • Native Resolution

    3,840 x 600

  • Brightness(Typ.,cd/m²)

    500

  • Contrast Ratio

    1,100:1

  • Viewing Angle (H x V)

    178 x 178

  • Response Time

    8ms (G to G)

  • Surface Treatment (Haze)

    10%

  • Lifetime

    50,000 Hrs (Typ.)

  • Operation Hours

    24Hrs / 7Days

  • Orientation

    Landscape & Portrait

POWER

  • Power Supply

    100-240V~, 50/60Hz

  • Power Type

    Built-in Power

POWER CONSUMPTION

  • Typ. / Max.

    220 W / 240 W

  • Smart Energy Saving

    100 W

SOFTWARE COMPATIBILITY

  • Content Management Software

    SuperSign CMS (The SuperSign Editor function is not supported.)

  • Control and Monitoring Software

    SuperSign Control/ Control+

  • Signage365Care

    Yes

STANDARD(CERTIFICATION)

  • Safety

    CB / NRTL

  • EMC

    FCC Class "A" / CE / KC

  • ErP / Energy Star

    Yes(EU Only) / No
