Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.88
Module Resolution (WxH)
160*90
Module Dimensions(WxH,mm)
300*168.75
No. of Modules per Screen (WxH)
12 × 12 (Total 144)
Screen Resolution (WxH)
1,920 × 1,080
Screen Dimensions (W x H x D, mm, including bezel)
3,605 x 2,030 x 29.95 (Thickest 59.5)
Screen Surface Area (㎡)
7.29
Weight of the screen
155
Physical Pixel Density (pixels/㎡)
284,444
Flatness of Cabinet (mm)
±0.15 (TBD)
Cabinet material
Aluminum
Service access
Front
Max. Brightness (After Calibration)
Typ. 500
Color Temperature
3,200~9,300
Visual Viewing Angle (Horizontal)
150
Visual Viewing Angle (Vertical)
150
Brightness Uniformity(%)
0.98
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
3,000:1
Processing Depth (bit)
16
Power Consumption (W/Screen, Max.)
2,000
Power Consumption (W/Screen, Avg.)
750
Power Consumption (W/㎡, Max.)
275
Heat Dissipation (BTU/h/Screen, Max.)
6,825
Heat Dissipation (BTU/h/Screen, Avg.)
2,560
Heat Dissipation (BTU/h/㎡, Max.)
939
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
0℃ to +40℃
Operating Humidity
10~90%RH
IP rating Front
IP30
IP rating Rear
IP30
Certification
CE,FCC,ETL,CB,CE-RED EMC Class A
Speaker
Built-in(9W+9W)
Environment
RoHS, REACH
Controller
Embedded(webOS)
I/O Port
HDMI(3), DP(1), USB, LAN, RS232C In/Out, IR, Digital Audio Out (1, SPDIF Optical) Wi-Fi/BT
