Certification
CE, FCC, ETL
Controller
CBAF-0151
Power Consumption (W/Cabinet, Max.)
210
Power Consumption (W/Cabinet, Avg.)
175
Power Consumption (W/m², Max.)
519
Heat Dissipation (BTU/h/Cabinet, Max.)
729
Heat Dissipation (BTU/h/Cabinet, Avg.)
599
Heat Dissipation (BTU/h/m², Max.)
1,775
Power Supply (V)
100 to 240
Frame Rate (Hz)
96 / 100 / 120
Refresh Rate (Hz)
7,680
LED Lifetime (Half brightness)
100,000
Operating Temperature (°C)
0 ℃ to +40 ℃
Operating Humidity
10 ~ 80%RH
Max. Brightness (After Calibration, nit)
1,500
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity
≥ 95%
Color Uniformity
±0.015Cx,Cy
Contrast Ratio
Max. 100,000:1
Processing Depth (bit)
16 (HDR10, HDR10 Pro)
Pixel Configuration
COB
Pixel Pitch (mm)
1.56
Module Resolution (W x H)
96 x 108
Module Dimensions (W x H, mm)
150 x 168.75
Weight per Module (kg)
0.15
No. of Modules per Cabinet (W × H)
4 x 4
Cabinet Resolution (W × H)
384 x 432
Cabinet Dimensions (W × H × D)
600 x 675 x 79.8
Cabinet Surface Area (m²)
0.405
Weight per Cabinet (kg/unit)
15.5
Weight per Square Meter (kg/m²)
38.3
Physical Pixel Density (pixels/m²)
409,600
Flatness of Cabinet (mm)
±0.15
Cabinet Material
Die Casting Magnesium Alloy
Service Access
Rear
Environment
RoHS/REACH
