Pixel Configuration
Single SMD
Pixel Pitch (mm)
1.88
Module Resolution (WxH)
160x180
Module Dimensions(WxH,mm)
300x337.5x13
Weight per Module (kg)
0.95
No. of Modules per Cabinet (WxH)
2x1
Cabinet Resolution (WxH)
320x180
Cabinet Dimensions (W x H x D, mm)
600x337.5x72
Cabinet Surface Area (㎡)
0.203
Weight per Cabinet (kg/unit)
6.5
Weight per Square Meter (kg/㎡)
32.0
Physical Pixel Density (pixels/㎡)
284,089
Flatness of Cabinet (mm)
±0.3
Cabinet material
Die-casting Aluminum
Service access
Front
90 degree corner cut
Yes
Max Brightness (After Calibration, nit)
600
Color Temperature (K)
3,200~9,300
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
150
Brightness Uniformity(%)
97%
Color Uniformity
±0.003Cx,Cy
Contrast Ratio
5,000:1
Processing Depth (bit)
14
Power Consumption (W/Cabinet, Max.)
103
Power Consumption (W/Cabinet, Avg.)
41
Power Consumption (W/㎡, Max.)
510
Heat Dissipation (BTU/h/Cabinet, Max.)
351
Heat Dissipation (BTU/h/Cabinet, Avg.)
140
Heat Dissipation (BTU/h/㎡, Max.)
1,740
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
-20℃ to +40℃
Operating Humidity
10~80%RH
IP rating Front
IP50
IP rating Rear
IP50
Certification
CE, FCC, cTUVus, CB, KC, CCC
Environment
RoHS, REACH
Controller
CVBA
