Versatile Series
Pixel Configuration
3 in 1 SMD
Pixel Pitch (mm)
2.97
Module Resolution (W x H)
84 × 168
Module Dimensions (W x H, mm)
250 × 500
Weight per Module (kg)
1.30
No. of Modules per Cabinet (W × H)
2 × 2 / 2 × 1 (Half-sized)
Cabinet Resolution (W × H)
168 × 336 / 168 × 168 (Half-sized)
Cabinet Dimensions (W × H × D)
500 × 1,000 × 74.88 / 500 × 500 × 74.88 (Half-sized)
Cabinet Surface Area (m²)
0.500 / 0.250 (Half-sized)
Weight per Cabinet (kg/Cabinet)
12.5 / 8.5 (Half-sized)
Weight per Square Meter (kg/m²)
25.0 / 34.0 (Half-sized)
Physical Pixel Density (pixels/m²)
112,896
Flatness of Cabinet
± 0.3 mm
Cabinet Material
Die Casting Aluminum Alloy
Service Access
Front or Rear (One Option Only)
Max Brightness (After Calibration)
1,000
Color Temperature
3,200-9,300 (K)
Visual Viewing Angle (Horizontal)
160
Visual Viewing Angle (Vertical)
160
Brightness Uniformity
97%
Color Uniformity
± 0.003 Cx,Cy
Contrast Ratio
7,000
Processing Depth (bit)
14
Power Consumption (W/cabinet, Max.)
270 / 135 (Half-sized)
Power Consumption (W/cabinet, Avg.)
90 / 45 (Half-sized)
Power Consumption (W/m², Max.)
540
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
2,880
Lifetime (Hours to Half Brightness)
100,000
Operating Temperature (°C)
-10 °C to +45 °C
Operating Humidity
0 - 80 % RH
IP rating Front / Rear
IP30 / IP30
Input Interface
HDMI / DP / OPS / USB
Input Resolution
3,840 x 2,160 @60Hz
Output Signal
Gigabit Ethernet (16 ea)
Output Fiber Optical
No
Control RJ45
Yes
Control USB
No
Electrical Power Consumption (W)
50
Electrical Power Supply (V)
AC 100-240 V
Mechanical Size (mm)
443 (W) × 307.5 (D) × 63 (H)
→ EIA Standard Rack (2U)
Mechanical Weight (kg)
4.9
Feature Signal Redundancy
Yes
Feature HDR10
Yes
Input Interface
HDMI / DVI
Input Resolution
1,920 x 1,200 @60Hz
Output Signal
Gigabit Ethernet (4 ea)
Output Fiber Optical
No
Control RJ45
No
Control USB
Yes
Electrical Power Consumption (W)
16
Electrical Power Supply (V)
AC 100-240 V
Mechanical Size (mm)
482.6 (W) × 250 (D) × 44.45 (H)
→ EIA Standard Rack (1U)
Mechanical Weight (kg)
2.9
Feature Signal Redundancy
Yes
Feature HDR10
No
Input Interface
HDMI / DVI / DP
Input Resolution
3,840 x 2,160 @60Hz
Output Signal
Gigabit Ethernet (16 ea)
Output Fiber Optical
4 ea
Control RJ45
Yes
Control USB
Yes
Electrical Power Consumption (W)
30
Electrical Power Supply (V)
AC 100-240 V
Mechanical Size (mm)
482.6 (W) × 250 (D) × 96 (H)
→ EIA Standard Rack (3U)
Mechanical Weight (kg)
4.6
Feature Signal Redundancy
Yes
Feature HDR10
Yes
