Pixel Configuration
Micro
Pixel Pitch (mm)
0.94
Module Resolution (WxH)
320 × 120
Module Dimensions(WxH,mm)
300 × 112.5
Weight per Module (kg)
0.19
No. of Modules per Cabinet (WxH)
2 × 3
Cabinet Resolution (WxH)
640 × 360
Cabinet Dimensions (W x H x D, mm)
600 × 337.5 × 44.9
Cabinet Surface Area (㎡)
0.2
Weight per Cabinet (kg/unit)
7.8
Weight per Square Meter (kg/㎡)
38.5
Physical Pixel Density (pixels/㎡)
1,137,778
Flatness of Cabinet (mm)
±0.5
Cabinet material
Aluminum
Service access
Front
Max Brightness (After Calibration, nit)
600 / Peak 1,500
Color Temperature (K)
3,200~9,300 / Default 7,300
Visual Viewing Angle (Horizontal)
160°
Visual Viewing Angle (Vertical)
160°
Brightness Uniformity(%)
0.95
Color Uniformity
±0.02Cx, Cy
Contrast Ratio
40,000:1 @10lux
Processing Depth (bit)
20 (HDR10, HDR10 Pro)
Power Consumption (W/Cabinet, Max.)
60
Power Consumption (W/Cabinet, Avg.)
43
Power Consumption (W/㎡, Max.)
296
Heat Dissipation (BTU/h/Cabinet, Max.)
205
Heat Dissipation (BTU/h/Cabinet, Avg.)
148
Heat Dissipation (BTU/h/㎡, Max.)
1,013
Power Supply (V)
100 to 240
Frame Rate (Hz)
50 / 60
Refresh Rate (Hz)
3,840
LED Lifetime (Half brightness)
100,000
Operating Temperature(℃)
0°C to +40°C
Operating Humidity
10-80% RH
IP rating Front
IP50
IP rating Rear
IP20
Certification
Safety 60950-1, EMC Class B, BS476 Part7 Class1
Environment
RoHS
Controller
CSAD
