UHD Standard Signage

86UH5J-H

Key Features

Brightness(Typ.) : 500 cd/m²
Surface Treatement (Haze) : 28%
Bezel : 14.3 mm (Even bezel)
Depth : 60.6 mm
Interface : HDMI(3)/ DP/ DVI-D/ USB 2.0/ RS232C/ RJ45/ Audio/ IR
Built-in Speaker

All Spec

ACCESSORY

Basic: Remote Controller(include battery 2ea), Power Cord, QSG, Regulation Book, Phone to RS232C Gender

Optional: OPS Kit(KT-OPSF), LSW640A/B(Wall Mount)

CERTIFICATION

Safety: CB / NRTL

EMC: FCC Class "A" / CE / KC

ErP / Energy Star: Yes (NewErP) / No (TBD)

CONNECTIVITY

Input: HDMI (3, HDMI1/HDMI2 : HDCP 2.2/1.4, HDMI3 : HDCP 1.4), DP (1, HDCP2.2/1.3), DVI-D (HDCP1.4), Audio In, RS232C IN (1, 4pin Phone-jack), RJ45(LAN), IR IN, USB2.0 Type A(1)

Output: HDMI Out, Audio Out, RS232C OUT (1, 4pin Phone-jack)

ENVIRONMENT CONDITIONS

Operation Temperature: 0°C to 40°C

Operation Humidity: 10 % to 80 %

KEY FEATURE

Key features: Internal Memory 16 GB, Built-in Wi-Fi, Temperature Sensor, Auto Brightness sensor, Acceleration(Gyro) Sensor, Local Key Operation, webOS6.0, Embedded CMS (Local Contents Scheduling, Group Manager), USB Plug & Play, Fail over, Background Image (Booting Logo Image, No Signal Image), Sync Mode (RS-232C Sync, Local Network Sync), Multi-screen (PIP, PBP (4)), Screen Share, Video Tag (4), Play via URL, Rotation (Screen Rotation, External Input Rotation), Gapless Playback, Tile Mode Setting (Max. 15 × 15), Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, 3rd Party Compatibility (Crestron Connected), Power (Smart Energy Saving, PM mode, Wake on LAN,Beacon, HDMI-CEC, SI Server Setting, webRTC, Pro:Idiom

LANGUAGE

OSD: English, French, German, Spanish, Italian, Korean , Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Turkish, Arabic

MECHANICAL SPECIFICATION

Bezel Color: Black

Bezel Width: Even bezel : 14.3mm

Weight(Head): 49.0Kg

Packed Weight: 72.5Kg (With Pallet)

Monitor Dimension(W x H x D): 1926.2 x 1097.2 x 60.6mm(without Handle and LG Logo)

Carton Dimensions(W x H x D) (Box outer size): 2073 x 1250 x 285mm

Handle: Yes

VESA<sup>TM</sup> Standard Mount Interface: 600 x 400

PANEL

Screen Size: 86

Panel Technology: IPS

Back Light Type: Edge

Aspect Ratio: 16 : 9

Native Resolution: 3840 x 2160 (UHD)

Refresh Rate: 120Hz

Brightness: 500nit (Typ.)

Contrast Ratio: 1,100:1

Dynamic CR: 1,000,000:1

Color Gamut: NTSC 72%

Viewing Angle(H x V): 178 X 178

Color Depth: 10bit, 1.07Billion colors

Response Time: 8ms (G to G)

Surface Treatment(Haze): 28%

Life time: 50,000Hrs (Typ.)

Operation Hours (Hours/Day): 24/7

Portrait / Landscape: Yes / Yes

POWER

Power Supply: AC 100-240V~, 50/60Hz

Power Type: Built-In Power

POWER CONSUMPTION

Typ.: 215W (TBD)

Max.: 280W (TBD)

BTU (British Thermal Unit): 733.69 BTU/Hr(Typ.), 955.5 BTU/Hr(Max) (TBD)

Smart Enegy Saving(~70%): 150.5W (TBD)

DPM: 0.5W

Power off: 0.5W

SOFTWARE COMPATIBILITY

SuperSign CMS: Yes

SuperSign Control / Control+: Yes / Yes

SuperSign WB: Yes

SuperSign Media Editor: Yes

Mobile CMS: Yes

Signage 365 Care: Yes

SOUND

Speaker: Yes

OPS COMPATIBILITY

OPS Type Compatible: Yes
