AC Power Cord
Yes
DC Cable length
1,500 mm
Dimensions(WxDxH, mm)
134 x 59.8 x 31mm
Input
100 ~ 240VAC
Output
19V/3.42A
Weight (kg)
0.9 kg
Cable
Power cord, Manin Cable 1m (LAN Cable, Sync cable Option)
CD
Manual, Calibration SW
Other
Book Manual, Outgonig Inspection sheet
Battery duration in standby status
Typ. 13 hrs
Dimensions(WxDxH, mm)
204.6*110.5*7.8
Nominal Capacity
30Wh (7.5V, 4000mAh)
Nominal Voltage
7.5V
Operation Time
Typ. 240 shots / 6.0 hrs (Condition : Interval Time 90 sec)
Type
Detachable
weight (g)
229.86
Bundle battery Q'ty
2
Charging Time
3 Hours
Dimensions (WxDxH, mm)
125 x 255.5 x 90.5 mm
Input voltage
19V
Output voltage
8.7V
Slot Q'ty
3
Weight (kg)
0.9kg
AC Power Cord
1.5m, White
Dimensions (WxDxH, mm)
125 x 255 x 109.8 mm
Power Input
AC100 to 240V, 47-63Hz
Power Output
DC24V/2.1A
Weight (kg)
1.3kg
A/D Conversion
16 bit
Auto Exposure Detection
Yes
Data Output
16 bit
Detachable Wire (Easy to plug / unplug)
Yes (Magnetic)
Expected lifetime (Gy)
100 Gy
Power unit interface
Connect to Control Box
Sensitivity degradation at the 'end of Life'
20%
Sensor
←
Shock monitoring
Yes
Spatial Resolution(lp/mm)
3.57 lp/mm
Unit Interface
Connect to Control Box
Wired Communication
Yes
WLAN
IEEE802.11a/b/g/n/ac, 2.4GHz/5GHz
X-ray generator voltage range
40 to 150kVp
X-ray period (ms) (=Window Time)
Standard: 500 ( ~4000)
DQE @ 0.1lp/mm
72%
DQE @ 0.5lp/mm
67%
DQE @ 1lp/mm
61%
DQE @ 2lp/mm
49%
DQE @ 3lp/mm
28%
Sensitivity( lsb/uGy ) / Programmable
Typ. 600 / Yes
Operating-Attitude
Less than 5000 m
Operating-Humidity
Less than 80% RH, No condensation
Operating-Pressure
70 ~ 106 kPa
Operating-Temperature
10 to 35 ℃
Storage-Attitude
Less than 12,192 m
Storage-Humidity
Less than 90% RH, No condensation
Storage-Pressure
50 ~ 106 kPa
Storage-Temperature
-20 to 60 ℃
LAN Cable (Control Box-PC) : Optional(When Buyer requires this cable, is shipped according to BOM)
(Option)
Length
1m10m15m
Sync Cable(Control Box - X-ray Generator) : Optional(When Buyer requires this cable, is shipped according to BOM)
(Option)
MTF @ 0.5lp/mm
89%
MTF @ 1lp/mm
74%
MTF @ 2lp/mm
47%
MTF @ 3lp/mm
29%
Cycle Time(Ethernet / WLAN)
8sec / 11 sec (Ethernet / WLAN)
Falling
40 Cm
Full Image(Raw Image)
Ethernet 3sec / WLAN 6 sec
Full Image
Wired 2 sec. (Typ.) Wireless 2.5 sec. (Typ.)
Image-lag (Typ.)
0.023%
Input
DC24V/2.1A
Maximum Load Weight
Full (Uniform Load) : 300kg
Local (Point Load) : 100kg
Number of Pixels
3072x3072
Pixel Pitch
140㎛
Power consumption
Typ. 19.0W (No Charging), 30.5W (with Charging)
Scintillator
Csi
Sensor protection plate
Carbon Fiber Plate
TFT Active Area(mm)
430.08×430.08 mm
TFT Dimensions(WxDxH, mm)
445 x 445 mm
TFT Type
A-Si
Weight(kg) / Icld. Battery (Typ.)
3.4kg
X-ray sensitive Area(mm)
430.08 x 430.08mm
X-ray sensitive Pixel
3072 x 3072
Anti-Bacteria
JIS Z 2801 0.99%
Cleaning and desinfecting products
Isopropanel 100%, Ethanol 70%, Cidex OPA, 0.9% Nacl solution
Watertightness
Durability IP53 rated
Warranty
36 Month
