All Spec
POWER
-
Power Supply
-
AC 100-240V~, 50/60Hz
-
Power Type
-
Built-in Power
SOUND
-
Speaker (Built-in)
-
NO
ACCESSORY
-
Basic
-
Remote Controller(include battery 2ea), IG(Installation Guide), Regulation Book
-
Optional
-
NO
LANGUAGE
-
OSD
-
English, Korean
CERTIFICATION
-
EMC
-
FCC Class "A" / CE / KC
-
ePEAT(US only)
-
NO
-
ERP / Energy Star
-
YES / NO
-
Safety
-
CB / NRTL
ENVIRONMENT CONDITIONS
-
Operation Humidity
-
10 % to 80 %
-
Operation Temperature
-
0 °C to 40 °C
OPS COMPATIBILITY
-
OPS Power Built-in
-
N/A
-
OPS Type compatible
-
N/A
POWER CONSUMPTION
-
BTU (British Thermal Unit)
-
1054 BTU/Hr(Typ.), 1085 BTU/Hr(Max.)
-
DPM
-
N/A
-
Max.
-
470W
-
Power off
-
0.5W
-
Smart Energy Saving (70%)
-
N/A
-
Typ.
-
139W (IEC 62087)
CONNECTIVITY (OLED PRO DEDICATED)
-
REF(Gen-Lock) In
-
YES
-
RJ45(GPI Remote) In
-
YES
-
RJ45(GPI Remote) Out
-
YES
-
SDI In
-
YES (4ea)
-
SDI Out
-
YES (4ea)
-
SFP+ In
-
YES
MECHANICAL SPECIFICATION
-
Weight (Head)
-
31Kg
-
Bezel Color
-
Black
-
Bezel Width
-
T/R/L/B : 2.0/2.0/2.0/2.0mm (Off Bezel) T/R/L/B : 8.7/8.9/8.9/11.6mm (On Bezel)
-
Carton Dimensions (W x H x D)
-
1670 x 1108 x 200mm
-
Handle
-
YES
-
Monitor Dimensions (W x H x D)
-
1446.3 x 823.8 x 49mm (without Control Box) 1446.3 x 853.8 x 56.5mm (with Control Box)
-
Monitor Dimension with Stand (W x H x D)
-
1446.3 x 896.5 x 272mm
-
Packed Weight
-
45.5Kg
-
VESA Standard Mount Interface
-
300 x 300 mm
-
Weight (Head+Stand)
-
35Kg
PANEL
-
Aspect Ratio
-
16:9
-
Back Light Type
-
OLED
-
Brightness
-
1000/900/500/180nit (APL 3%/10%/25%/100%)
-
Color Depth (Number of Colors)
-
1.07 Billion colors
-
Color Gamut
-
DCI-P3 99%
-
Contrast Ratio
-
1,850,000:1
-
Dynamic CR
-
NO
-
Life time
-
30,000Hrs (Typ.)
-
Native Resolution
-
3840 x 2160 (UHD)
-
Panel Technology
-
OLED
-
Portait / Landscape
-
NO / YES
-
QWP (Quarter Wave Plate)
-
N/A
-
Refresh Rate
-
120Hz
-
Response Time
-
0.1ms (G to G)
-
Screen Size (Inch)
-
65
-
Surface Treatment (Haze)
-
Haze 0%
-
Transparency
-
N/A
-
Viewing Angle (H x V)
-
178º x 178º
SPECIAL FEATURE
-
Conformal Coating (Power Board)
-
YES
-
Direct Sunlight
-
N/A
-
IP Rating
-
N/A
-
Overlay Touch Compatibility
-
N/A
-
Power Protection
-
N/A
-
Smart Calibration
-
N/A
-
Tilt (Face down)
-
N/A
-
Tilt (Face up)
-
N/A
CONNECTIVITY
-
Audio In
-
NO
-
Audio Out
-
YES
-
Daisy Chain
-
NO
-
DP In
-
NO
-
DP Out
-
NO
-
DVI-D In
-
NO
-
External Speaker Out
-
NO
-
HDMI In
-
YES (2ea)
-
HDMI In (HDCP Ver.)
-
2.2/1.4
-
HDMI Out
-
NO
-
IR In
-
NO
-
IR Out
-
NO
-
RGB In
-
NO
-
RJ45(LAN) In
-
YES (1ea)
-
RJ45(LAN) Out
-
NO
-
RS232C In
-
YES
-
RS232C Out
-
NO
-
Touch USB
-
NO
-
USB In
-
USB2.0 Type A (1ea)
SOFTWARE COMPATIBILITY
-
Connected Care
-
NO
-
Mobile CMS
-
NO
-
Promota
-
NO
-
SuperSign Cloud
-
NO
-
SuperSign CMS
-
NO
-
SuperSign Control+
-
NO
-
SuperSign WB
-
YES
FEATURE - HARDWARE
-
Acceleration(Gyro) Sensor
-
NO
-
Auto Brightness Sensor
-
NO
-
BLU Sensor
-
NO
-
Current Sensor
-
NO
-
FAN (Built-in)
-
NO
-
Humidity Sensor
-
NO
-
Internal Memory (eMMC)
-
8GB
-
Local Key Operation
-
YES
-
Pixel Sensor
-
NO
-
Power Indicator
-
YES
-
Proximity Sensor
-
NO
-
Temperature Sensor
-
YES
-
Wi-Fi/BT (Built-in)
-
NO
DEDICATED FEATURE - OLED PRO
-
3rd Party Cal. SW Compatibility
-
CalMAN - including Uniformity Compensation, 9p/13p/25p, EBU Grade1
-
AFD (Active Format Description)
-
NO
-
Aspect Ratio
-
Auto, Original, Full Wide, 4:3, 14:9, 13:9, 1.85:1, 2.35:1, 1:1
-
Audio - Dolby Atmos
-
YES
-
Audio - Level Meter
-
YES
-
Audio - Sound Mode
-
NO
-
Audio - Source Selection
-
YES
-
Calibration SW
-
SuperSign WB - including Uniformity Compensation, 9p/13p/25p, EBU Grade1
-
Caption
-
YES
-
Color Adjustment
-
OLED Light, Brightness, Contrast, Chroma, Sharpness, Tint, White Balance Control
-
Color Temp.
-
VAR Temp/9300K/6500K/5400K/3200K/D65(6504K)/C(6774K)/D-Cinema(6302K)
-
Custom 3D LUT file Import (through USB)
-
NO
-
DeltaE < 2
-
YES
-
EOTF(Electro-Optical Transfer Function)
-
Auto/User/1.9/2.2/2.4/2.6/SDR(Calibration)/ST.2084 PQ/BT.2100 HLG/HDR(Calibration)
-
Eyesafe Certification
-
YES
-
False Color
-
NO
-
Function Key
-
YES
-
Gamut
-
HDR Gamut / SDR Gamut
-
Genlock
-
YES
-
GPI Control (General Purpose Interface)
-
YES
-
HDR/SDR monitoring
-
YES
-
Internal Signal Pattern
-
YES
-
LG Connect
-
YES
-
Marker
-
YES
-
Marker - Center Marker
-
YES
-
Marker - Safety Area
-
YES
-
Mastering Peak
-
YES
-
Mono/Blue Only
-
YES
-
OLED Panel Setting (for image sticking prevention)
-
TPC Auto-dimming (Temporal Peak Luminance Control), Pixel Refresher, Screen Shift, Logo Luminance Adjustment, GSR Auto dimming (Global Sticky Reduction), CPC (Convex Power Control)
-
Over scan
-
Zero Scan, Over Scan, Under Scan
-
Peaking Filter (Camera Focus Assist)
-
NO
-
Profile Load / Save
-
YES
-
R/G/B Gain
-
-768~255
-
SDI Color Format
-
Auto, RGB444, YCbCr444, YCbCr422
-
Support Web API
-
YES
-
Tally
-
YES
-
Time Code
-
YES
-
Transfer Matrix
-
YES
-
UMD (Under Monitor Display)
-
YES
-
Video Analysis - Vector Scope
-
YES
-
Video Analysis - Waveform
-
YES
-
Video Range
-
NO
-
VPID
-
YES
-
Zoom
-
x2~x5
FEATURE - SOFTWARE
-
ISM Method
-
YES
-
OS Ver. (webOS)
-
webOS 5.0
-
PBP
-
YES (2PBP)
-
PIP
-
YES
