Cooling¹ (Min. ~ Rated ~ Max.) (kW)
2.88~ 8.25 ~ 10.55
Cooling¹ (Min. ~ Rated ~ Max.) (Btu/h)
9,800~ 28,200 ~ 36,000
Cooling² (Min. ~ Rated ~ Max.) (kW)
2.88~7.20~10.55
Cooling² (Min. ~ Rated ~ Max.) (Btu/h)
9,800~ 24,600 ~ 36,000
Heating (Min. ~ Rated ~ Max.) (kW)
4.19~8.80~10.55
Heating (Min. ~ Rated ~ Max.) (Btu/h)
14,300~30,000~36,000
Cooling¹ (Rated) (kW)
2.27
Cooling² (Rated) (kW)
2.83
Heating (Rated) (kW)
2.30
Cooling¹ / Heating (W / W)
12.40 / 3.85
Power Supply (V , Ø , Hz)
220-230-240, 1, 50/60
Dimensions (W x H x D) (mm)
950 x 834 x 330
Net Weight (kg (lbs))
56.6
Compressor Type
Twin Rotary
Refrigerant Type
R410A
Fan Motor Type
BLDC
Sound Pressure Level Cooling (Rated) (dB(A))
51.00
Sound Pressure Level Heating (Rated) (dB(A))
53.00
Piping Connections Liquid (Outer Dia.) (mm (inch))
Φ9.52 (3/8)
Piping Connections Gas (Outer Dia.) (mm (inch))
Φ15.88 (5/8)
Piping Length (Max.) (m (ft))
50
Maximum Height Difference Outdoor Unit ~ Indoor Unit (Max.) (m (ft))
30
Power Supply (V , Ø , Hz)
220-230-240, 1, 50/60
Dimensions Body (W x H x D) (mm)
1,050 x 330 x 1,050
Net Weight (kg (lbs))
30
Air Flow Rate (H / M / L) (m3/min)
25.0 / 21.0 / 19.0
Fan Motor Type
BLDC
Sound Pressure Level Cooling (H / M / L) (dB(A))
44.0 / 40.0 / 38.0
Sound Pressure Level Heating (H / M / L) (dB(A))
47.0 / 43.0 / 40.0
