Open Frame
All specs
ACCESSORY
-
Basic
Remote Controller, Power Cord, IR Extension Kit, HDMI Cable, Manual (ESG&EIG)
-
Optional
Wi-Fi Dongle (AN-WF500)
CONNECTIVITY
-
External Control
RS232C In/Out, RJ45 In, IR Receiver In
-
Input
HDMI (2), DP, DVI-D, Audio, USB
-
Output
DP, External Speaker
ENVIRONMENT CONDITIONS
-
Operation Humidity
10 % to 80 %
-
Operation Temperature
0℃ to 50℃
(w/o Direct Sunlight or with Cooling Systems in Direct Sunlight)
PANEL
-
Brightness (Typ., cd/m²)
3000
-
Resolution
1,920 x 1,080 (FHD)
-
Screen Size
55" (54.64" Measured Diagonal)
PHYSICAL SPECIFICATION
-
Bezel Width
9.9mm (L/R),12mm (T/B)
-
Monitor Dimension (W x H x D)
1,235.5 x 709.4 x 106.8 mm
-
Weight (Head)
26.5kg
POWER
-
Power Supply
100-240V~, 50/60Hz
-
Power Type
Built-In Power
POWER CONSUMPTION
-
Smart Energy Saving
120 W
-
Typ./Max
250 W / 300 W
SOFTWARE COMPATIBILITY
-
Content Management Software
SuperSign CMS
-
Control and Monitoring Software
SuperSign Control+ / Control
STANDARD(CERTIFICATION)
-
EMC
FCC Class "A" / CE / KC
-
Safety
IEC 60950-1 / EN 60950-1 / UL 60950-1
