55" 500 nits FHD 0.9mm Even Bezel Video Wall

Features Gallery Specs Support
Enquire To Buy

55" 500 nits FHD 0.9mm Even Bezel Video Wall

55VM5B-A

55" 500 nits FHD 0.9mm Even Bezel Video Wall

55"
(1)
Borderless Design

Borderless Design

Narrow Bezel
Borderless design with its 0.9mm even panel bezel* and 1.8mm BtB(Bezel to Bezel)** size, verifi ed by Nemko***, enables immersive and seamless viewing experiences on assembled video wall screens.
Built-in SoC* and Synced Playback
Smart Platform

Built-in SoC* and Synced Playback

The optimized built-in quad-core SoC in the 55VH7B/VM5B can play various content formats and eliminates the need for an external media player. Using its built-in SoC, each display plays its video tile without lag for synchronized content playback.

*SoC: System-on-Chip.

webOS 2.0
Smart Platform

webOS 2.0

The webOS 2.0 platform provides easy and
convenient tools to create contents. LG's SDK*
and technical supports make content development and management easier.

*Software Development Kit.

Clear Viewing Angle
Superior Picture Quality

Clear Viewing Angle

The 55VH7B/VM5B ensures clear picture quality even when installed in stacks of more than four. This is very favorable for the quantity of video walls installed in large spaces.

*The angle from the center of the screen to have 50% of the initial luminance.

Uniform Brightness
Superior Picture Quality

Uniform Brightness

LG's LED backlight technology guarantees high uniformity in brightness to ensure a clear picture. On other screens, certain spots may appear darker than others, but the new 55VH7B/VM5B generates high visibility and a consistent brightness across the whole screen.
Video Wall Image Creation
Superior Picture Quality

Video Wall Image Creation

Through Video Wall Image Creation (VIC) technology, color and brightness differences are compensated in circuit part with an algorithm to make the panels into a same characteristic so that each video wall maintains the consistent white balance.
Image Gap Reduction
Superior Picture Quality

Image Gap Reduction

The 55VH7B/VM5B, 49VH7C/VM5C includes an image improvement algorithm that can adjust to objects located in the boundary of bezel for a seamless viewing experience.
Enhanced Content Management

Enhanced Content Management

LAN Daisy Chain Performance
A LAN daisy chain allows you to execute commands to control and monitor the screens and even update their firmware.
Guide Bracket / Classified Port
Convenient Options

Guide Bracket / Classified Port

A guide bracket is an attachment that ensures the video wall remains flat. The classified in/out port prevents errors when connecting a daisy chain.
Control Buttons
Convenient Options

Control Buttons

With 8 control buttons, it's easy to operate various functions of the 55VH7B/VM5B, such controlling the OSD (On Screen Display) and changing the input source.
Print

All specs

ACCESSORY

Optional

Wall Mount (Landscape : WM-L640V, Portrait : WM-P640V), OPS Kit (KT-OPSA), HDBaseT (EB-B100)

CONNECTIVITY

External Control

RS232C, RJ45, IR Receiver

Input

HDMI, DP, DVI-D, OPS, Audio, USB 2.0, USB3.0, RGB

Output

DP, Audio

ENVIRONMENT CONDITIONS

Operation Humidity

10 % to 80 %

Operation Temperature

0°C to 40°C

MEDIA PLAYER COMPATIBILITY

External Media player Attatchable

Yes (MP500/MP700)

OPS type compatible

Yes

PANEL

Aspect Ratio

16 : 9

Brightness (Typ., cd/m²)

500

Resolution

1,920 x 1,080 (FHD)

Screen Size

55"

PHYSICAL SPECIFICATION

Bezel Width

0.9mm (Top/Bottom/Left/Right even bezel) / 1.8mm *B to B : Panel Bezel + Panel Bezel

Monitor Dimension (WxHxD) mm

1,211.4 x 682.2 x 86.5

VESA™ Standard Mount Interface

600 x 400mm

Weight (Head)

18.6kg

POWER

Power Supply

100-240V~, 50/60Hz

Power Type

Built-In Power

POWER CONSUMPTION

Smart Energy Saving

80 W

Typ. / Max.

150 W

SOFTWARE COMPATIBILITY

SuperSign-c

Yes

SuperSign-w lite

Yes

STANDARD(CERTIFICATION)

EMC

FCC Class "A" / CE / KCC

ErP / Energy Star

NA / Yes (Energy Star 6.0)

Safety

UL / cUL / CB / TUV / KC
