- Pro:Centric Smart IPTV Platform
- Embedded Pro:Idiom decryption for non-Pro:Idiom TV's
- IP Streaming (TA type supports RF Tuning)
- Supports 720p/ 1,366x768 /1,080p /2,160p output resolutions
- Pro:Centric Application Support for non-Pro:Centric TVs
- webOS 5.0 based
All specs
HOSPITALITY FEATURE
Diagnostics
YES (IP Remote)
HTNG-CEC (Version)
YES (1.4)
IR Out
YES (RS-232C)
Simplink(HDMI-CEC) (Version)
YES (1.4)
SNMP
YES
USB Cloning
YES
Wake on RF
YES
WOL
YES
External Speaker Out / Line Out
YES (Line Out)
EzManager
YES
Hotel Mode / PDM / Installer Menu
YES
Insert Image
YES
Instant ON
YES
Lock mode
YES (Limited)
Modular Interface
YES (60pin Interface)
Multi IR Code
YES
Port Block
YES
RJP (Remote Jack Pack) Compatibility
YES
V-Lan Tag
YES
INFO
Category
Settop Box
STANDARD
EMC
YES
Safety
YES
AUDIO (SOUND)
AI Acoustic Tuning
YES (Ready, MMR Required)
AI Sound
YES
LG Sound Sync
YES
DIMENSIONS/WEIGHT
Dimension in Shipping (W x H x D)
366 x 143 x 218 mm
Dimension (W x H x D)
233 x 180.5 x 29.8 mm
Weight
0.72 kg
Weight in Shipping
1.85 kg
POWER SPEC.
Power Consumption(Max)
60W
Power Consumption(Typ)
STB only : 17.6W STB + Exp Module : 47.5W
Power Supply (Voltage, Hz)
DC IN : 19V/2.7A
Standby Power Consumption
Under 0.5W
ACCESSORIES
AC Adaptor
YES
Cables
HDMI, RS232 (Phone to RS232C)
VIDEO
Output Resolution
2160p / 1080p / 1366x768 / 720p
VERTICAL FUNCTION (CORPORATE/RETAIL)
BEACON
YES
NTP sync timer
YES
SMART FUNCTION
Bluetooth
YES
Bluetooth Audio Playback
YES
DIAL
YES
Gallery Mode
YES
IoT
YES
Magic Remote Compatibility
YES (Ready)
Screen Share
YES
Soft AP
YES
Voice Recognition (Standalone/Solution)
YES
webOS version
webOS 5.0
Web Browser
YES
Wi-Fi
YES
CONNECTIVITY
Audio Line Out(3.5mm Phone jack)
YES
DC Adapter In
YES
Digital Audio Out (Optical)
YES
Expansion slot (60pin)
YES
External RS-232C control (4pin Phone Jack)
YES
EXT. IR In
YES
HDMI In
YES (2ea)
HDMI Out
YES (1ea)
RF In
YES (1ea)
RJ45 (Usage Purpose)
1 (Ethernet)
RS-232C (D-Sub 9pin / Phone jack)
YES (Phone jack)
Service Port (For Debugging)
YES
USB (Ver.)
YES(2ea / 2.0)
HOSPITALITY SOLUTION
Pro:Centric Direct
YES
Pro:Centric Server
YES
Pro:Centric Smart
YES
Pro:Centric V
YES
Pro:Idiom (DRM)
YES
Pro:Idiom Media (DRM)
YES
Quick Menu (Customizable Portal)
YES
webRTC (Real Time Communication)
YES
