Outdoor Touch Open-frame Display
OSD
English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Türkçe, Arabic
Bezel Color
Black
Bezel Width
T/R/L/B : 25.5/30.5/30.5/25.5mm
Carton Dimensions (W x H x D)
644 x 406 x 207mm
Handle
NO
Monitor Dimensions (W x H x D)
557.3 x 322.8 x 60mm
Monitor Dimension with Stand (W x H x D)
N/A
Packed Weight
8Kg
VESA Standard Mount Interface
100 x 100 mm
Weight (Head)
7.0Kg
Weight (Head+Stand)
N/A
Power Supply
AC 100-240V~, 50/60Hz
Power Type
Built-in Power
Speaker (Built-in)
NO
Basic
Remote Controller(including battery 2ea), Power Cord, Manual (EIG, IG), RS-232C Gender
Optional
NO
Response Time ('Paint' app on Windows 10 PC)
N/A
Accuracy (Typ.)
N/A
Interface
N/A
Available Object Size for Touch
N/A
Multi Touch Point
N/A
Operating System Support
N/A
Protection Glass Thickness
N/A
Protection Glass Transmission
N/A
OPS Power Built-in
NO
OPS Type compatible
NO
EMC
FCC Class "A" / CE / KC / VCCI
ePEAT(US only)
NO
ERP / Energy Star
YES / NO
Safety
CB / NRTL
Operation Humidity
10 % to 80 %
Operation Temperature
0 °C to 50 °C
BTU (British Thermal Unit)
290 BTU/Hr(Typ.), 393 BTU/Hr(Max.)
DPM
0.5W
Max.
115W
Power off
0.5W
Typ.
85W (Full White) 37W (IEC 62087)
Aspect Ratio
16:9
Transparency
N/A
Contrast Ratio
1,000:1 (Typ.)
Viewing Angle (H x V)
178º x 178º
Back Light Type
Edge
Brightness
1,500nit (Typ., with Glass)
Color Depth (Number of Colors)
16.7 Million colors
Color Gamut
NTSC 72%
Dynamic CR
800,000:1
Life time
70,000Hrs (Typ.)
Native Resolution
1920 x 1080 (FHD)
Operation Hours (Hours/Day)
24/7
Panel Technology
IPS (AHVA)
Portait / Landscape
YES / YES
QWP (Quarter Wave Plate)
YES
Refresh Rate
60Hz
Response Time
25ms (G to G)
Screen Size (Inch)
21.5
Surface Treatment (Haze)
Haze 25%
Anti-Reflective
N/A
Degree of Protection
N/A
Infrared - Resistance (IR)
N/A
Shatter-Proof
YES
Tempered / Chemical strengthening
Tempered strengthening
Thickness
3mm
Conformal Coating (Power Board)
YES
Direct Sunlight
YES
IP Rating
IP66 (front only)
Overlay Touch Compatibility
N/A
Power Protection
N/A
Smart Calibration
N/A
Tilt (Face down)
N/A
Tilt (Face up)
N/A
Audio In
NO
HDMI In
YES (1ea)
Audio Out
NO
Daisy Chain
NO
DP In
NO
DP Out
NO
DVI-D In
NO
External Speaker Out
YES
HDMI In (HDCP Ver.)
1.4
HDMI Out
NO
IR In
NO
IR Out
NO
RGB In
NO
RJ45(LAN) In
YES (1ea)
RJ45(LAN) Out
NO
RS232C In
YES
RS232C Out
YES
Touch USB
YES
USB In
USB2.0 Type A (1ea)
Connected Care
YES
Mobile CMS
NO
Promota
YES
SuperSign Cloud
NO
SuperSign CMS
YES
SuperSign Control+
YES
SuperSign WB
NO
Acceleration(Gyro) Sensor
YES
Auto Brightness Sensor
YES
BLU Sensor
NO
Current Sensor
NO
FAN (Built-in)
YES
Humidity Sensor
YES
Internal Memory (eMMC)
16GB
Local Key Operation
NO
Pixel Sensor
NO
Power Indicator
YES
Proximity Sensor
NO
Temperature Sensor
YES
Wi-Fi/BT (Built-in)
NO
Auto Set ID
NO
Backlight Sync
NO
Beacon
NO
Booting Logo Image
YES
Brightness Compensation
NO
Cisco Certification
NO
Control Manager
YES
Crestron Connected
NO
External Input Rotation
YES
Fail over
YES
Gapless Playback
YES
Group Manager
YES
HDMI-CEC
YES
ISM Method
YES
Local Contents Scheduling
YES
Local Network Sync
YES
Network Ready
YES
No Signal Image
YES
OS Ver. (webOS)
webOS 4.1
PBP
NO
PIP
NO
Play via URL
YES
PM mode
YES
Pro:Idiom
YES
RS232C Sync
NO
Scan Inversion
NO
Screen Rotation
YES
Screen Share
NO
Setting Data Cloning
YES
SI Server Setting
YES
Smart Energy Saving
YES
SNMP
YES
Status Mailing
YES
Tile Mode Setting
NO
USB Plug & Play
YES
Video Tag
YES (4 Video Tag)
Wake on LAN
YES
webRTC
YES
W/B Setting by Grey scale
NO
