55" 4000 nits FHD IP-rated Outdoor Display
All specs
ACCESSORY
Basic
Remote Controller, Manual(EIG, IG , OM), Regulation Book, Phone to RS232C Gender, HDMI Cable , POWER CABLE
CONNECTIVITY
Input
HDMI(2), DP, HDBaseT, USB(2)
Output
External Speaker Out(L/R)
External Control
RS232C In/Out, RJ45(LAN) In/Out
ENVIRONMENT CONDITIONS
Operation Temperature
-30°C to 50 °C
Operation Humidity
5 % to 100 %
PANEL
Screen Size
55
Panel Technology
IPS, M+(WRGB)
Backlight Type
Direct
Aspect Ratio
16:09
Native Resolution
1,920 x 1,080 (FHD, WRGB)
Brightness (Typ., cd/m²)
4000
Brightness (Min., cd/m²)
3200
Contrast Ratio
1,000:1
Dynamic CR
500,000:1
Viewing Angle (H x V)
178 x 178
Response Time
Typ. 9ms (G to G BW)
Surface Treatment (Haze, Quarter Wave Plate)
Haze 3%, QWP
Local dimming
48 Blocks
Life Time (Typ.)
50,000 Hrs
Operation Hours
24 Hrs
Orientation
Portrait & Landscape
PHYSICAL SPECIFICATION
Protection Glass
5mm(IK 10, Degree of Protection, Chemical Strengthening, Anti-Reflective)
Bezel Color
Black
Bezel Width
38.4mm(T/B), 26.0mm(L/R)
Weight (Head)
40kg
Monitor Dimension (W x H x D)
1,292.5 x 737.4 x 88.0mm
Packing Dimensions (W x H x D)
1,446 x 890 x 207 mm
Packed Weight
45kg
Handle
X
POWER
Power Supply
100-240V~, 50/60Hz
Power Type
Built-In Power
POWER CONSUMPTION
Typ./Max
310/390W
Smart Energy Saving
170W
SOFTWARE COMPATIBILITY
SuperSign
Yes(CMS, Control)
Signage365Care
Yes
STANDARD(CERTIFICATION)
Safety
CB / NRTL
EMC
FCC Class "A" / CE / KCC
ErP / Energy Star
No / NA
